Telit

As one of the most important wireless networking equipment manufacturers, Telit offers high-performance 4G LTE, 3G, 2G, Hybird modules for worldwide customers. With nearly twenty years as a pioneer and leader in enterprise-grade products and software, Telit has earned a reputation for solving the toughest challenges in the Internet of Things (IoT). Telit Wireless Solutions is an enabler of the global machine-to-machine (m2m) movement. Being a global, leading manufacturer, Telit offers a portfolio of integrated products, platforms and services to support and enable IoT deployments from things to apps. The portfolio provides cellular modules, GNSS and short-to-long range wireless products and applications as well as connectivity services.

Telit

Telit cellular modules are mainly including:

  • > LPWA, 4G LTE, 3G, 2G, HYBRID modules for standard & industrial grade
  • > Secure, Nested Smart Modules for Automotive Grade
  • > Mini PCIe and M.2. Networking Modules for data cards

Telit puts the products to three groups:

  • > Standard & Industrial Grade Modules
  • > Nested automotive cellular modules
  • > mPCIe and M.2 modules

According to the supported LTE network type, LTE Category and IoT applications, we summarized the Telit modules and put them into four groups:

  • > Telit 4G LTE/LTE-A embedded modules
  • > Telit IoT(LPWA, Cat-M1, Cat-NB1, Cat.1) Modules
  • > Telit 3G UMTS/HSPA+/HSPA/CDMA Modules
  • > Telit 2G GRPS/GSM Modules

You can find the Telist embedded cellular module list for the four groups as below.

Telit LTE Cat-M and NB-IoT modules

Telit 4G modules are leading the trend of LTE technology development. The Telit LTE advanced and LTE-A Pro modules are the only few LTE modules available now in the market since 2018. Other Telit LTE Modules are also being used in many terminals for different network carriers worldwide. Below is the Telit 4G LTE Module list for LTE/LTE-A/LTE-A networks. The table also shows the LTE Category, LTE frequency bands, speeds, price, specs and target region for the Telit LTE modules

Telit 4G LTE/LTE-A Embedded Modules List
Model
Category Form Factor
LTE Frequency Bands
Peak Speed
Price/USD

Specs

Target Region
Telit LM960 LTE Cat.18
Mini PCIe
B1, B25(B2), B3, B66(B4), B26(B5), B7, B8, B12(17), B13, B14, B20, B28, B29(DL), B30, B32(DL), B38, B39, B40, B41, B42, B46(DL), B48, B71  DL 1.2Gbps/UL150Mbps 499.00 Telit LM960 Specs Worldwide
Telit LM940 LTE Cat.11
Mini PCIe
B1-5, B7, B8, B12, B13, B17, B20, B25, B26, B28, B29, B30 (Rx only), B66, B38, B40, B41 DL 600Mbps/UL 150Mbps 329.00 Telit LM940 Specs Worldwide
Telit LN94x Series
Telit LN940A11 LTE Cat.11
PCIe M.2
B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B21, B25, B26, B28, B29, B30, B38, B39, B40, B41, B66 DL 600Mbps/UL 50Mbps 329.00 Telit LN940A11 Specs Europe and APAC
Telit LN940A9 LTE Cat.9
PCIe M.2
B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B21, B25, B26, B28, B29, B30, B38, B39, B40, B41, B66 DL 450Mbps/UL 50Mbps 279.00 Telit LN940A9 Specs North America, Europe, and APAC
Telit LN941A6-E1 LTE Cat.6
PCIe M.2
B1, B3, B7, B8, B20, B28, B32 DL 300Mbps/UL 50Mbps 249.00 Telit LN941A6-E1 Specs Europe
Telit LN93x Series

Telit LN930 LTE Cat.4
PCIe M.2
B1-5, B7, B8, B13, B17, B18, B19, B20 DL 150Mbps/UL 50Mbps 129.00 Telit LN930 Specs North America, Europe, roaming in Asia Pacific
Telit LN930-AP LTE Cat.4
PCIe M.2
B1, B3, B8, B9, B11, B18, B19, B21, B26 DL 150Mbps/UL 50Mbps 129.00 Telit LN930-AP Specs Asia Pacific
Telit LN932 LTE Cat.6
PCIe M.2
B1, B2, B3, B4, B5, B7, B8, B9, B13, B17, B18, B19, B20, B25, B26, B29, B38, B41 DL 300Mbps/UL 50Mbps 179.00 Telit LN932 Specs North America, Europe, roaming in Asia Pacific
Telit LN932-AP LTE Cat.6
PCIe M.2
B1, B2, B3, B5, B7, B8, B9, B11, B18, B19, B20, B21, B25, B26, B28, B38, B39, B40, B41 DL 300Mbps/UL 50Mbps 189.00 Telit LN932-AP Specs Asia Pacific
Telit LN933-NA LTE Cat.4
PCIe M.2
B2, B3, B4, B5, B7, B17, B20 DL 150Mbps/UL 50Mbps 159.00 Telit LN933-NA Specs North America
Telit LE922 Series

Telit LE922A6-E2 LTE Cat.6
LGA
B3, B7, B8, B20, B28, B32 DL 300Mbps/UL 50Mbps 229.00  Telit LE922A6-E2 Specs Europe
Telit LE922A6-E1 LTE Cat.6
LGA
B3, B7, B20 DL 300Mbps/UL 50Mbps 229.00  Telit LE922A6-E1 Specs Europe
Telit LE922A6-A1 LTE Cat.6
LGA
B1, B3, B7, B28, B40 DL 300Mbps/UL 50Mbps 229.00  Telit LE922A6-A1 Specs Australia
Telit LE910 V2 Series

Telit LE910-SV V2 LTE Cat.4
LGA
B2, B4, B13 DL 150Mbps/UL 50Mbps 169.00  Telit LE910-SV V2 Specs North America(Verizon)
Telit LE910-NA V2 LTE Cat.4
LGA
B2, B4, B5, B12, B13 DL 150Mbps/UL 50Mbps 169.00  Telit LE910-NA V2 Specs North America(AT&T, T-Mobile)*
Telit LE910-AU V2 LTE Cat.4
LGA
B3, B7, B28 DL 150Mbps/UL 50Mbps 169.00  Telit LE910-AU V2 Specs Australia/New Zealand (Telstra)
Telit LE910-EU V2 LTE Cat.4
LGA
B1, B3, B7, B8, B20 DL 150Mbps/UL 50Mbps 169.00  Telit LE910-EU V2 Specs Europe
Telit LE910B4-NA LTE Cat.4
LGA
B2, B4, B5, B12, B13 DL 150Mbps/UL 50Mbps 169.00 Telit LE910B4-NA Specs North America (AT&T)
Telit xE940 Series
Telit LE940A9 LTE Cat.9
LGA
DL 450Mbps/UL 50Mbps 289.00 Telit LE940A9 Specs Automotive Smart module
Telit LE940B6 LTE Cat.6
LGA
DL 300Mbps/UL 50Mbps 269.00 Telit LE940B6 Specs Automotive Smart module



IoT(the Internet of Things) is a fast growing market. As the leading IoT manufacturers and IoT solution provider, Telit offers the broadest portfolio of certified and compatible cellular modules, system-on-modules (SoM), terminals, and reference designs in multiple family form factors. For over 30 years, Telit has been enabling connectivity across a variety of market segments including energy, manufacturing, retail, transportation, smart buildings, gateways and routers, and more.

To meet the various demand for IoT applications, Telit offers a range of LTE IoT modules including:

  • > Telit LE910 Cat.1 Series (LTE Cat.1)
  • > Telit LE910B1 Series (LTE Cat.1)
  • > Telit LE910C1 Series (LTE Cat.1)
  • > Telit ME910C1 series (LTE Cat M1/NB1)
  • > Telit ML865C1 Series (LTE Cat M1/NB1)
  • > Telit LE866 Series (LTE Cat.1)
  • > Telit ME866A1 Series (LTE-M)
  • > Telit NE866B1 Series (LTE NB-IoT)
  • > Telit NE910C1 Series (LTE NB-IoT)
  • > Telit NL865B1 Series (LTE NB-IoT)
  • etc....



Below is the list of Telit IoT modules, incluging Telit LTE Cat.1 modules, Telit LTE Cat-M modules, Telit LTE Cat NB-IoT modules. They are all Telit LPWA modules.

Telit LTE IoT (LPWA, LTE Cat.1, Cat-M, Cat NB-IoT) Modules List
Model
Category Form Factor
LTE Frequency Bands
Peak Speed
Price/USD

Specs

Target Region
Telit LE910C4-NF LTE Cat.1/Cat.4
LGA
B12, B14, B4, B2, B5, B13, B66, B71  Cat.4: DL 150Mbps/UL 50Mbps
Cat.1: DL 10Mbps/UL 5Mbps
 189.00 Telit LE910C4-NF Specs North Americas (AT&T, Verizon and T-Mobile)
Telit LE910 Cat1 Seires

Telit LE910-SV1 LTE Cat.1
LGA
B2, B4, B13 DL 10Mbps/UL 5Mbps  89.00 Telit LE910-SV1 Specs North America (Verizon)
Telit LE910-SVL LTE Cat.1
LGA
B4, B13 DL 10Mbps/UL 5Mbps  89.00 Telit LE910-SVL Specs North America (Verizon)
Telit LE910-NA1 LTE Cat.1
LGA
B2, B4, B5, B12, B13 DL 10Mbps/UL 5Mbps  89.00 Telit LE910-NA1 Specs North America (AT&T, T-Mobile)*
Telit LE910-EU1 LTE Cat.1
LGA
B1, B3, B7, B8, B20 DL 10Mbps/UL 5Mbps  89.00 Telit LE910-EU1 Specs Europe
Telit LE910-JN1 LTE Cat.1
LGA
B1, B19, B21 DL 10Mbps/UL 5Mbps  89.00 Telit LE910-JN1 Specs Japan (NTT DoCoMo)
Telit LE910B1 Series

Telit LE910B1-NA LTE Cat.1
LGA
B2, B4, B5, B12, B13 DL 10Mbps/UL 5Mbps  89.00 Telit LE910B1-NA Specs North America (AT&T)*
Telit LE910B1-SA LTE Cat.1
LGA
B1, B19, B21 DL 10Mbps/UL 5Mbps  89.00 Telit LE910B1-SA Specs North America (AT&T)*
Telit LE910C1 Series

Telit LE910C1-NA LTE Cat.1
LGA
B2, B4, B12 DL 10Mbps/UL 5Mbps   89.00 Telit LE910C1-NA Specs North America(AT&T and global roaming)
Telit LE910C1-AP LTE Cat.1
LGA
B1, B3, B5, B8, B28 DL 10Mbps/UL 5Mbps   89.00 Telit LE910C1-AP Specs APAC/ANZ (Telstra/Vodafone AU)
Telit LE910C1-NS LTE Cat.1
LGA
B2, B4, B5, B12 DL 10Mbps/UL 5Mbps   89.00 Telit LE910C1-NS Specs North America(Sprint)
Telit LE910C1-EU LTE Cat.1
LGA
B1, B3, B7, B8, B20, B28A DL 10Mbps/UL 5Mbps   89.00 Telit LE910C1-EU Specs EMEA
Telit ME910C1 Series

Telit ME910C1-NV LTE Cat M1/NB1
LGA
B4, B13 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-NV Specs North America (Verizon)
Telit ME910C1-NA LTE Cat M1/NB1
LGA
B2, B4, B12 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-NA Specs North America (AT&T)*
Telit ME910C1-N1 LTE Cat M1/NB1
LGA
B2, B4, B12, B13 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-N1 Specs North America
Telit ME910C1-E1 LTE Cat M1/NB1
LGA
B3, B8, B20 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-E1 Specs Europe
Telit ME910C1-E2 LTE Cat M1/NB1
LGA
B3, B8, B20 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-E2 Specs Europe
Telit ME910C1-AU LTE Cat M1/NB1
LGA
B3, B5, B8, B28 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-AU Specs Australia
Telit ME910C1-J1 LTE Cat M1/NB1
LGA
B1, B3, B8, B18, B19, B26 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-J1 Specs Japan
Telit ME910C1-WW LTE Cat M1/NB1
LGA
B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B26, B28, B39 Cat.M1: DL 300Kbps/UL 375Kbps
Cat.NB1: DL 250kbps/UL 250Kbps
129.00 Telit ME910C1-WW Specs Worldwide
Telit ML865C1 Series

Telit ML865C1-EA LTE Cat M1/NB1
LCC
B1, B3, B5, B8, B18, B19, B20, B26, B28 Cat-M1: DL 300kbps/UL 375Kbps
Cat-NB1: DL 250kbps/UL 250Kbps
89.00 Telit ML865C1-EA Specs Europe + APAC
Telit ML865C1-NA LTE Cat M1
LCC
B2, B4, B12, B13 DL 300kbps/UL 375Kbps 89.00 Telit ML865C1-NA Specs North America(Verizon, AT&T)
Telit LE866 Series
Telit LE866-SV1 LTE Cat.1
LGA
B4, B13 DL 10Mbps/UL 5Mbps 79.00 Telit LE866-SV1 Specs North America (Verizon)
Telit LE866A1-NA LTE Cat.1
LGA
B2, B4, B12 DL 10Mbps/UL 5Mbps 79.00 Telit LE866A1-NA Specs North America (AT&T, T-Mobile)*
Telit LE866A1-KK LTE Cat.1
LGA
B3, B8 DL 10Mbps/UL 5Mbps 79.00 Telit LE866A1-KK Specs Korea(Korea Telecom)
Telit LE866A1-JS LTE Cat.1
LGA
B1, B8 DL 10Mbps/UL 5Mbps 79.00 Telit LE866A1-JS Specs Japan(Softbank)
Telit ME866A1 Series
Telit ME866A1-NV LTE-M (Cat M1)
LGA
B4, B13 DL 300kbps/UL 375Kbps 79.00 Telit ME866A1-NV Specs North America(Verizon)
Telit ME866A1-NA LTE-M (Cat M1)
LGA
B2, B4, B12 DL 300kbps/UL 375Kbps 79.00 Telit ME866A1-NA Specs North America(AT&T)
Telit NE866B1 Series

Telit NE866B1-E1 LTE NB-IoT(NB1)
LGA
B8, B20 DL 250kbps/UL 20Kbps 129.00 Telit NE866B1-E1 Specs Europe and APAC
Telit NE910C1 Series
Telit NE910C1-E1 LTE Cat NB-IoT
LGA
B8, B20 DL 250kbps/UL 20Kbps 89.00 Telit NE910C1-E1 Specs Europe
Telit NL865B1 Series
Telit NL865B1-E1 LTE Cat NB1
LCC
B8, B20 DL 250kbps/UL 20Kbps 79.00 Telit NL865B1-E1 Specs Europe + APAC



As the compensation for Telit LTE modules, Telit 3G modules are also being used in some  cases. The Telit 3G Modules support various UMTS/HSPA/HSPA+ or CDMA networks in LGA or B2B form factor. Below you can check the Telit 3G UMTS/HSPA+/HSPA/CDMA module list:

Telit 3G HSPA/UMTS & CDMA Modules List
Model
Category Form Factor
3G Frequency Bands
Peak Speed
Price/USD

Specs

Telit HE910 Series
Telit HE910-G UMTS/HSPA+
LGA
800/850/900/AWS1700/1900/2100MHz DL 21Mbps/UL 5.76Mbps  89.00 Telit HE910-G Specs
Telit HE910-DG UMTS/HSPA+
LGA
800/850/900/AWS1700/1900/2100MHz DL 21Mbps/UL 5.76Mbps  89.00 Telit HE910-DG Specs
Telit HE910-D UMTS/HSPA+
LGA
800/850/900/AWS1700/1900/2100MHz DL 21Mbps/UL 5.76Mbps  89.00 Telit HE910-D Specs
Telit HE910-GL UMTS/HSPA+
LGA
800/850/900/AWS1700/1900/2100MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-GL Specs
Telit HE910-EUR UMTS/HSPA+
LGA
800/850/900/2100MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-EUR Specs
Telit HE910-EUD UMTS/HSPA+
LGA
800/850/900/2100MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-EUD Specs
Telit HE910-EUG UMTS/HSPA+
LGA
800/850/900/2100MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-EUG Specs
Telit HE910-NAR UMTS/HSPA+
LGA
800/850/AWS1700/1900MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-NAR Specs
Telit HE910-NAD UMTS/HSPA+
LGA
800/850/AWS1700/1900MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-NAD Specs
Telit HE910-NAG UMTS/HSPA+
LGA
800/850/AWS1700/1900MHz DL 7.2Mbps/UL 5.76Mbps  89.00 Telit HE910-NAG Specs
Telit UE910 Series

Telit UE910-GL UMTS/HSPA
LGA
800/850/900/1900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE910-GL Specs
Telit UE910-EUR UMTS/HSPA
LGA
900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE910-EUR Specs
Telit UE910-EUD UMTS/HSPA
LGA
900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE910-EUD Specs
Telit UE910-NAR UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE910-NAR Specs
Telit UE910-NAD UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE910-NAD Specs
Telit UL865 Series

Telit UL865-EUR UMTS/HSPA
LGA
900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UL865-EUR Specs
Telit UL865-EUD UMTS/HSPA
LGA
900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UL865-EUD Specs
Telit UL865-NAR UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UL865-NAR Specs
Telit UL865-NAD UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UL865-NAD Specs
Telit UL865-BR UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UL865-BR Specs
Telit UE866 Series

Telit UE866-N3G UMTS/HSPA
LGA
850/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE866-N3G Specs
Telit UE866-EU UMTS/HSPA
LGA
900/2100MHz DL 7.2Mbps/UL 5.76Mbps   Telit UE866-EU Specs
Telit HS3002 Series

Telit HS3002-NA UMTS/HSPA+
B2B
850/2100MHz DL 3.6Mbps/UL 3.6Mbps   Telit HS3002-NA Specs
Telit HS3002-EU UMTS/HSPA+
B2B
900/2100MHz DL 3.6Mbps/UL 3.6Mbps   Telit HS3002-EU Specs
Telit HS3002-AU UMTS/HSPA+
B2B
850/2100MHz DL 3.6Mbps/UL 3.6Mbps   Telit HS3002-AU Specs
Telit HE920 Series

Telit HE920-EU UMTS/HSPA+
LGA
850/900/2100MHz DL 14.4Mbps/UL 5.76Mbps   Telit HE920-EU Specs
Telit HE920-NA UMTS/HSPA+
LGA
850/1700/1900MHz DL 14.4Mbps/UL 5.76Mbps   Telit HE920-NA Specs


Telit HS3001 CDMA/1xRTT
B2B
800/1900MHz DL 153.6Kbps   Telit HS3001 Specs
Telit WE922-3GR WiFi
LGA
      Telit WE922-3GR Specs
Telit HE922-3GR UMTS/HSPA+
LGA
800/900/1900/2100MHz DL 21Mbps/UL 5.76Mbps Telit HE922-3GR Specs







Items 1 to 12 of 63 total

per page

Page:
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5

Items 1 to 12 of 63 total

per page

Page:
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
