ZTE 3HuiTube MF282 4G LTE Router

The 3HuiTube, successor of 3WebCube, is the new wireless router for Austrian mobile operator Three Austria. The HuiTube is not black and angular, but white and round and offers complimentary wireless internet access as LTE connectivity for home.

Features and characteristics of the 3HuiTube
Manufacturer and type designation: ZTE MF282 3HuiTube
Chipset: not known
LTE Category: CAT4
Download rate up: Up to 150 Mbit/s
Upload rate to: Up to 50 Mbit/s
Supported LTE bands 800 MHz/1800 MHz/2600 MHz
Backward compatible with: DC-HSPA+ / UMTS / GMS
Support of LTE-Advanced No
MIMO Support: Yes, 2×2
External antenna connector: Yes, 3G / 4G via TS-9 (Buy 3HuiTube Antenna)
Telephone
With integrated telephone system: No
Connector for ISDN telephones: No
Connection for analog telephones: Yes (RJ11)
DECT: No
Integrated answering machine: No
Network | LAN & WLAN
LAN Ports: 1x Gigabit LAN (RJ45)
WLAN Standards: WLAN 802.11 a/b/g/n/ac
5 GHz WLAN support: Yes
Encryption: WPS, WEP, WPA, WPA2
Wireless Internet Hotspot function: Yes, for up to 64 devices
Others
Battery pack: No
Dimension: 128 x 107 mm
USB: No
Memory card expansion: No
Release: October 2015
available at: www.4gltemall.com

Technical Features







The 3HuiTube is also constructed unusual: The router part sitting on a dock and can be removed to make it operate with its own plug directly into an AC outlet. A colored LED ring on the lid indicates whether and which network the device just uses.

Configuration in the Web

The operating system of the router produced by Chinese manufacturer ZTE, based on Linux 2.6. On a special website, you can configure the router. Here the user can also program a timer, for example, so that the wireless LAN function turns off automatically at night. About the Bridge mode, you can also directly disable the wireless function. Besides the usual encryption as WPA2, a firewall is installed. Additional features include port forwarding, DynDNS, guest-Fi and DHCP server. The installation should be easy.

WiFi & connections

The 3HuiTube could support WiFi 802.11 a/b/g/n/ac, both on the 2.4 GHz and 5 GHz bands (dual band) with 2 × 2 MIMO. The router automatically chooses to request the best wireless channel. User can also choose the channel, using the Channel Analysis of the device. According to operator “3”, 3HuiTube can work as a wireless hotspot for up to 64 devices. The router has a Gigabit LAN port (RJ45) and a connection for an analog telephone (RJ11). The webCube has incidentally two TS-9 sockets.





WiFi via mobile



After the SIM card is inserted, the router only needs to be connected to the home network and is then ready for operation. Unfortunately, ZTE has not installed CAT6 module, so with LTE category 4 at 150 Mbit/s downstream and 50 Mbit/s upload is final. If there is no LTE network available, it can continue surfing via HSPA+ with up to 42 Mbit/s.





Availability & Price

The ZTE 3HuiTube is offered by Austria operator 3 in combination with the LTE tariffs. If you would like unlocked 3HuiTube, welcome to check the online store www.4gltemall.com for SIM free units.





Vodafone B4000 4G LTE Wireless Router Review

Vodafone will begin with LTE-Advanced and already announced a matching router B4000 at Cebit that should dominate the improved LTE technology for the first time. With the new model B4000,  user could achieve the fastest possible speed on LTE-Advanced network. Below you can learn all about the key data for the new top model.

Features and characteristics of Vodafone B4000

Manufacturer and type designation

Huawei E5186s-22 (HiSilicon chip)

Download rate up

Up to 300 MBit/s

Upload rate up

Up to 50 Mbit/s

Supported LTE bands:

LTE 2600 MHz/2100 MHz/1800 MHz/900 MHz/800 MHz (FDD) LTE + 2600 MHz TDD

LTE-Advanced Support

yes (the first time)

backward compatible with:

HSPA, HSPA+; UMTS (900/2100 MHz); GSM

MIMO Support:

MIMO 2×2

Connector for external antenna

yes, 2 SMA sockets(Buy Vodafone B4000 Antenna)

Category:

LTE category 6 modem

Telephone

With integrated PABX

Yes, VOIP SIP Client

VoLTE Suppor (Voice over LTE)

Yes

Connection for analog phones

Yes, 2xRJ11

DECT

No

integrator with Voice Mail

–

Network | LAN & WLAN

LAN Ports

4 LAN Gigabit ports (RJ45)

Wi-Fi standards

WLAN 802.11b/g/n/ac for up to 64 users

5 GHz Wi-Fi support

Yes

Coding

WEP, WPA, WPA2

USB

yes, 1 x USB 2.0

Mass weight

194 x 177 x 64 mm at 450 grams

Information material

Manual

“Not yet available online

available at

 www.4gltemall.com







Before B4000 is presented, there was no doubt that Vodafone B3000 was probably more of a “snapshot”. Here now Vodafone B4000 is available, which looks like the predecessor Vodafone B3000 and B2000. From the specifications, you can find the B4000 has new features and improvements. From the back label, we can find the Vodafone B4000 comes from original factory model Huawei E5186s-22 with a Vodafone logo branded, Huawei is the top Chinese hardware manufacturer.



First LTE-Advanced Router

The B4000 will be Vodafone’s first router that dominated the superfast LTE-Advanced, with the Category 6 with possibly 225-300 Mbit/s download speed. Customers will benefit from higher data rates at home or office when best network is available. Vodafone B4000 could support the  Vodafone network on LTE 800 MHz and the band around 2600 MHz which is primarily only available in urban areas.

Technical parameters

You can see some general technical specification on the box. In terms of wired and wireless features, you may refer to the technical datasheet. All the 4 LAN ports are finally designed for Gigabit and WLAN module dominates the latest standard, the wireless also transfer rates are possible in the gigabit range. Accordingly, it can be done in 5 GHz for the first time. The previous models were only compatible up to 802.11n and offered no 5 GHz.



Vodafone B4000 supports LTE Bands 1/3/7/8/20 and 38, so it support TDD network while the Vodafone B3000 can only work with FDD networks. In addition, the router is backwards compatible with the popular 3G and 2G standards, when LTE is not available even temporarily. The unit also has 2 USB ports (bottom and sides), and 2 SMA connectors for connecting an external antenna.



Telephone

Two telephones can be connected and operated via VOIP. What’s more, Vodafone B4000 supports the first “real” Voice over LTE, also named VoLTE. In 2014, the leading LTE providers start with this innovative technology, which promises including improved voice quality and lightning fast call setup.



Conclusion

The Vodafone B4000 has latest 4G technology for new networks, and it could fully replace the previous model such as B3000, B2000, B1000. Here now it’s already available on www.4gltemall.com . If you like it or want the unbranded factory model Huawei E5186s-22, welcome to check 4gltemall.com.







Vodafone B3000 4G LTE Wireless Router Review

With the B3000 router, Vodafone has the new LTE router which would replace the predecessor B2000 and B1000. Of course, the new router Vodafone B3000 has upgraded technical specifications and some new features for the ongoing LTE network modernization. Find out here what the LTE router excels and where are differences from the B2000.

Features and characteristics of Vodafone B3000

Manufacturer and Original Model

Huawei B593s-22

Download rate up

Up to 150 MBit/s

Upload rate up

Up to 50 Mbit/s

Supported LTE bands:

LTE (FDD) 2600MHz/2100 MHz/1800MHz/900MHz/800MHz
LTE (TDD) 2600MHz

Backward compatible with:

HSPA, HSPA+; UMTS (900/2100 MHz); GSM

MIMO Support:

MIMO 2×2

Connector for external antenna

yes, 2 SMA sockets(Buy Vodafone B3000 Antenna)

Category:

LTE modem category 4 (CAT4)

Telephone

With integrated PABX

Yes, VOIP SIP Client

Connection for analog phones

Yes, 2xRJ11

DECT

No

integrator with Voice Mail

–

Network | LAN & WLAN

LAN Ports

4 LAN ports (RJ45)

Wi-Fi standards

WLAN 802.11b / g / n for up to 32 users

5 GHz Wi-Fi support

No

Coding

WEP, WPA, WPA2

USB

yes, 2x USB 2.0

Mass weight

194 x 177 x 64 mm at 450 grams

Information material

Manual

Not yet available online

available since …

May 2014

Comparison of other models

“All” B “router models at a glance

Available at …

www.4gltemall.com



Technology



From the appearance, it’s hard to find differences with the B2000. On the front body, there is Vodafone logo, however, on the back stock, we can find the it’s based on the new version of the B593 from Huawei, the label indicates the model is B593s-22. The most important innovation: The LTE modem can now also handle LTE category 4. Therefore, theoretically it can achieve data rates of 150Mbps. However, LTE CAT4 is currently only available in urban centers, i.e big cities with over 100 thousand residents.

Unfortunately, Wi-Fi with AC standard is not yet on the list of specifications. Users must therefore continue to take a maximum of 802.11n to be surf. What’s more, the B3000 provides 4 LAN ports on the back along with 2 USB ports.



Telephone and reception



Through two RJ11 jacks, analog telephones can be operated via VOIP. A SIP client is integrated. Since IP telephone with LTE for home is not a shortcoming, demanding users will however still rather resort to a Fritz box, as regards this point. In terms of wireless network compatibility, the B3000 could support all major LTE bands in Europe, including LTE FDD 800/900/1800/2100/2600MHz and TDD 2600MHz.



In addition, of course, it would work well with all relevant 3G and 2G predecessor standards, including the 3G data turbo DC-HSDPA+, which allowed data rates of up to 42.2 Mbit/s. The Vodafone B3000 doesn’t have SIM lock, so it can be used to beyond Germany or user can change provider to other network operators.

Availability

The first New customers will receive the B3000 since about April 2014. Now the Vodafone B3000 is available on www.4gltemall.com at good price. Since it’s already one year, here now there are more new LTE wireless routers available with new features, such as Vodafone B4000, Huawei E5186. If you want a router with future proof, you can check more details about the new LTE category routers.

ZTE MF282 3HuiTube LTE Router from 3 Austria

HuiTube, which is a pretty unusual name for an LTE router. But it is the latest router model of 3 Austria, which is already on sale. The 3HuiTube has a imposing Video advertised and was presented as the continuous model from 3WebGate 3 and 3WebCube 3. The 3HuiTube comes form the Chinese manufactuer ZTE, the model number is ZTE MF282.

Based on LTE category 4 technology, HuiTube could reach up to 150 MBit/s for download via LTE, the uplink up to 50 Mbit/s. In addition to fast wireless ac, the 3HuiTube includes time switching function, and the router also supports LAN connections.

Design is at the forefront
At first glance, it is clear that the 3HuiTube is not like an ordinary LTE router looks, but can provide a thoroughly chic design. The device consists of two parts, with blue LEDs for an interesting lighting of the device. The round shape is by no means commonplace. The 3HuiTube makes sure a good figure in the home, in contrast to many other router models and it needs not to hide behind the cabinet.



Good Features
The 3HuiTube has three ports next to the connector for the external power supply, the three  connectors include: one type RJ11 for analog phones, a type RJ45 (Gigabit LAN) and also connections for an external antenna. Invisible from the outside, the technology is in the body: There is an LTE Cat4 modem for speeds of up to 150 Mbit/s in download and up to 50 Mbit/s for upload speeds, and it will also automatically switch to UMTS for up to 42.2 Mbit/s (DC-HSPA+) when LTE network is not available.

Also inside the WLAN module, the manufacturer ZTE has built here a dual-band module with support for 2.4 GHz and 5 GHz, WLAN 802.11ac speed up to 1167 Mbit/s is theoretically possible. Of course, the router is backward compatible with older wireless standards. A maximum of 32 devices can be connected simultaneously to the router.

The 3HuiTube also offers some interesting software functions. For example, the best WLAN frequency band is selected automatically to achieve the best performance. Also, you can configure the wireless network so that it is turned on only at certain times. This timer can be settled through the web interface of the router, there you could also find the other settings.

Free for new contract
The 3HuiTube is now available in white color on www.4gltemall.com, if you get the device through the network provider 3 from Austria, you may need get the tariff simultaneously. Here on www.4gltemall.com you can get the unlocked 3HuiTube without any contract. You can use the device with any network providers in Europe. To have a unique and fashion wireless router, ZTE MF282 3HuiTube may be a good option for you. If you prefer other brand, the similar products, such as Huawei E5180 and E5170 Webcube, are recommended.





O2 ZTE MF823D 4G LTE USB Stick

ZTE had offered a new LTE surfstick for Germany network providers. The model ZTE MF823 is for 1&1. The brother model ZTE MF823D is also available for the operator O2. Below are the details features for ZTE MF823D.



LTE features and Characteristics of ZTE MF823

Manufacturer and Model

ZTE MF823D

Download rate up

Up to 100 MBit/s

Upload rate up

Up to 50 MBit/s

Compatible LTE Bands

LTE800, LTE900, LTE1800, LTE 2600MHz

Backward compatible with:

DC-HSPA+, UMTS, EDGE, GPRS

MIMO Support:

MIMO 2×2

Connector for external antenna

Yes; 2 aerial socket type TS-9 available(Buy ZTE MF823D Antenna)

LTE Category:

LTE modem category 3 (3GPP Release 8)

Chipset

Qualcomm

Others

Dimensions

90 mm x 28.4 mm x 13 mm

USB standard

USB 2.0

Memory card expansion

Yes; MicroSD up to 32 GB

Compatible Operating Systems

Windows XP, Windows Vista, Windows 7, Mac OS (from 10.4)



Technical Specifications



The ZTE MF823 from Chinese telecommunications equipment vendor ZTE, replaces the current model MF821D from O2. All thing should be mentioned that ZTE MF823 is not the best USB stick when the ZTE MF825 is also in its product range. It supports LTE category 3 (max. 100 Mbit) and therefore with all networks from O2. In any case, the mobile service provider can offer data connections on the basis of category 4, which allows data rates up to 150 Mbps. It supports the LTE frequencies at 800, 900, 1800 and 2600 MHz – for operation in European countries. Likewise, the MF823 could also support DC-HSPA+ (to 42.2 Mbps), UMTS and GSM networks.





Unlike the Speed Stick 4 by Telekom, the stick fortunately has two connectors for an external antenna – optional to improve reception. Like almost all other models, user can insert a MicroSD memory card of up to 32GB of storage space for data of all kinds.





Others

Users do not have to install an extra software for the MF823, which would be auto connect to network. It is controlled conveniently from the browser via the web interface. It is enough to enter the following IP in the browser: http://192.168.3.1. The interface shows all important data at a glance. And you can see, how much volume you have already used in the current billing month. The stick is also compatible with the IPv6 protocol. According to the manufacturer ZTE, the MF823 uses about 1/4 less power than even the previous generations. It’s special for operation on a laptop or tablet. We are also pleased that quite modest dimensions of the model. At just 13 mm in height and 26 grams, it is one of the shallower representatives of its kind. It is alleged that the world’s smallest LTE data modem. Important to mention would be that there is no SIM lock, so the drive can be used with Contract card of other network operators.



Conclusion

The ZTE MF823 for O2 can provider users at an acceptable price for mobile Internet. With slim size and decent network support, it could be good partner for laptop. It’s available on www.4gltemall.com . But if you want to find better models, the Speed Stick III or the Huawei E3276, may be good options, but they are also more expensive.



Huawei E5786 4G LTE Cat6 Mobile Hotspot

Huawei E5786 is one of the first routers with CAT6 in the world. Even in the summer of 2014, the model E5786 came on the market. Below are the key data of the huawei E5786 Mobile Hotspot for reference.

LTE features and characteristics of Huawei E5786

Manufacturer and model

Huawei E5786 Mobile Wi-Fi

Download rate

Up to 300 MBit/s

Upload rate rate

Up to 50 MBit/s

Compatible LTE Bands

800, 1800, 2100, 2600 MHz

Backward compatible with

LTE CAT 3 & 4, DC-HSPA+, HSPA+, HSDPA, UMTS, EDGE, GPRS, GSM

Support of LTE-Advanced

Yes

MIMO Support:

MIMO 2×2

Connector for external antenna

Yes; 2 aerial socket type TS-9 available(Buy Huawei E5786 Antenna)

LTE Category

LTE modem of Category 6 (CAT6)

Chipset

Hisilicon | HPM Coretx A9 processor

Wi-Fi standards

802.11 a / b/g/n/ac

Wireless Internet Hotspot function

yes – for up to 10 devices

Others

Dimensions (WxHxD)

106 x 66 x 15.9 mm at 155 grams

USB standard

USB 2.0

Memory card expansion

Yes; MicroSD up to 32 GB

Compatible Operating Systems

Win XP, Vista, Windows 7 & 8, Mac OS (from 10.4)

Release

since September via Telekom

Manual PDF

“Manual load (in English only)

Available at

www.4gltemall.com

Huawei E5786



The Chinese manufacturer Huawei introduced the world’s first MiFi router E5786 for LTE-Advanced at the Mobile World Congress in February 2014. The E5786 should be the first mobile router with support for LTE CAT6. But the rival ZTE has a similar device called “ZTE Flare”. This seems at higher quality than the counterpart of Huawei.





LTE-Advanced Router



As already indicated, Huawei E5786 is the first LTE-Advanced equipment with Category 6(CAT6). The current LTE networks comply with category 3 and 4 (CAT 3/4), which take 100-150 Mbit/s for download speed, but with Cat.6, the speed of 300 MBit/s could be achieved for download, practically doubling the current level. However, these data rates will initially only be available in selected cities and probably seldom achieved in practice.



Portable CAT6 Wi-Fi router



The Mini-Router supports LTE to almost all popular bands. For example, 800, 1800, 2100 and 2600 MHz. Of course, it dominated Carrier aggregation at cat.6 and can thus achieve up to 300 Mbits downlink and 50 MBit upload rate. Besides the supported earlier LTE categories, it supports as well as 3G and 2G wireless standards. The Huawei E5786 sets chip on Huawei Hisilicon with a HPM Cortex 9 processor while ZTE flare has a modern block Qualcomm Gobi 9 × 30 chipset in ultrathin 20nm technology.

Users can set up a Wi-Fi hotspot for up to 10 other terminals to log in, and over all popular wireless standards (802.11 a/b/g/n/ac). Data can be exchanged internally with up to 300 Mbit/s via WLAN AC. The operation runs in the dual-band, so either to 2.4 or 5 GHz.





Others



Negative falls on first, that the battery is not removable. The capacity is with 3000 mAh, practically high standard. This should make up 10 hours of online work or 500 hours standby.

As usual, the Operation can be carried out via the browser. Per QR codes, which can be displayed optionally on the display let you integrate quickly into smartphones network, which considerably facilitates the establishment. In addition, Huawei has a special app that can monitor and configure your wireless network. The interface informs the used traffic and provides the wireless data rate represents a graphical trend. There are connections for external antennas and a Micro SD slot. The antenna format is TS-9 here.

Availability

The Germany Telekom has the identical model in the form of “Speedport II mini” as an OEM version. The original Huawei E5786 was available on the online trade store www.4gltemall.com . If you like the unlocked original version Huawei E5786, welcome to have a check.



Huawei Honor Cube WS831 Wireless 802.11ac Router

Recently, we tested several Huawei home routers. The powerful platforms and attractive price are interesting. However, the software can not always satisfy demanding users.

Huawei WS831 Wireless Router

In this article we look at the router Huawei Honor Cube WS831, which also has a second name “Honor Cube” in some sources.



This Honor Cube model has wired ports 100 Mbit/s (one WAN and two LAN), two wireless access points in the 2.4 and 5 GHz, and it supports the current protocol 802.11ac, and is equipped with a USB 2.0 port for connecting external storage devices.



In testing, we used the unlocated devices, so it was difficult to find even English letters on the box and in the instructions and in the web interface. Provided that this model is not on the manufacturer’s website, and not even any documents, it is possible that we will miss some of the features of the device.

Huawei WS831 Wireless Router

Packing router has an almost cubic shape and unusual celadon. No technical information on it, apparently, except for references to a faster processor, support for 802.11ac and company management utilities for mobile devices.

Huawei WS831 Wireless Router

The package includes the router power supply 5.1 V 2.1 A flat Gigabit Ethernet patch cable, a brief description, a warranty card and, as a bonus, the calendar for this year.

Huawei WS831 Wireless Router



The body of the router is made of white glossy plastic. Its dimensions are 90 × 90 × 94 mm. The top cover is printed the name of the series – Honor.

On the edge, the slit are passive ventilation. The second group of holes can be seen in the lower part of the housing.

Huawei WS831 Wireless Router



On the front side is a button «Hi» with chrome rim and a built-in multi-color display, which probably used to connect wireless clients on technology WPS, and reset (with a long press).

All connectors are assembled on the rear panel – input power supply, one port WAN, LAN port and two port USB 2.0. Turn the power of this model is not provided.

Huawei WS831 Wireless Router



The bottom of the selected gray matte is plastic. Based housing has two large rubber inserts that hold it firmly on a flat surface. But you can not fix this model on the wall. There is also a sticker with information about the device, where you can find the wireless network name by default, MAC- and IP-address, serial number and other data.



The main processor unit can be found labeled “5650”. The network has information about the fact that he is a SoC HiSilicon SD5650H with a pair of ARM-cores running at 1 GHz. Given the absence of heat sinks on the chip, and the use of wired ports only at 100 Mbit/s, it is hard to believe in these characteristics. The RAM of the device is 128 MB, and has 16 MB of flash memory for firmware. The Fast Ethernet controller for network is built into the main processor.

Huawei WS831 Wireless Router

The model is equipped with two radio blocks: Realtek RTL8192ER responsible for 802.11b/g/n 2.4GHz, and Realtek RTL8812AE for 802.11a/n/ac 5 GHz. Both chips use a configuration of two MIMO antennas that gives the maximum connection speed of 300Mbit/s and 876 Mbit/s, respectively. On the radio blocks, there are no radiators. Antennas are built-in in the model and are on opposite inner walls of the body.



The Huawei Honor Cube Ws831 is a cool wireless router with high speed for download. So if you would like it, welcome to purchase from www.4gltemall.com .



Huawei E5180 LTE Cube Review

The Austrian provider A1 Telekom Austria presented an 4G/LTE+Internet box( also a new LTE router), the model number is Huawei LTE Cube E5180, which is hidden technically. The Box proves that a router does not have to look dull or even ugly: The technology of E5180 puts in a chic, white square whose design amazingly reminiscent of Apple.

Features and characteristics of Huawei LTE Cube E5180
Manufacturer and type designation Huawei E5180 LTE Cube
Download rate Up to 150 MBit/s
Upload rate Up to 50 MBit/s
Supported LTE bands: 800 MHz/1800 MHz/2600 MHz
LTE-Advanced Support No
Backward compatible with: UMTS; GSM; HSPA+
MIMO Support: MIMO 2×2
Connector for external antenna No
Category: LTE modem category 4 (CAT4)
Telephone
With integrated PABX No
VoLTE Support (Voice over LTE) No
Operating Internet (VOIP) Yes
Connection for analog phones yes, 1 x RJ11
Connection for ISDN phones No
DECT No
integrator with Voice Mail No
HD voice possible No
Network | LAN & WLAN
LAN Ports 1 LAN (RJ45), 100 Mbit/s
Wi-Fi standards WLAN 802.11b / g / n for up to 32 devices
5 GHz Wi-Fi support No
Coding WPA, WPA2, WPS
WLAN guest access installable ev. not available
Others
USB No
Mass weight 110 x 70 x 70 mm / 250 g
IPv6 Support k. A.
NAS capability No
Power consumption ca. k. A.
used as a Media Server No
Information material
Manual: Not yet available as a PDF
available since … 01/11/2014
Available at www.4gltemall.com

Technical Features



With 11 x 7 x 7 centimeters and 250 grams in weight, the A1 Internet box 4G/LTE E5180 is portable enough to be used as a mobile LTE router. The micro-SIM card comes in a slot on the bottom of the unit. In addition to the technical specifications, the design attracts the eyes. It is probably no exaggeration to say that Huawei E5180 is the currently most fashionable LTE router in the world.



Mobile Internet



With the support LTE Category 4 and provided an appropriate collective as well as a developed network, Huawei E5180 Cube could achieve download speeds of up to 150 Mbit/s and 50 Mbit/s speeds for upload at 800, 1,800 and 2,600MHz. If no LTE network available, thanks to the support of DC-HSPA+, the E5180 Cube could reach download speed up to 42 Mbit/s. The only drawback that we could find in the router: It has incomprehensibly no connections or ports for external antennas. Therefore, one should keep a close eye on reception quality. If the signal is weak, you should move the location of the cube.



Wireless LAN



Up to 32 devices in the house can be supplied with the A1 Internet box 4G/LTE E5180 via WLAN. The connection is elegantly solved: By pressing the blue backlit lid of the box, Wi-Fi 802.11 b/g/n is activated. Huawei promises a wireless range of up to 250 meters with a possible maximum speed of 300 Mbit/s.



Safety



At the same time, the cover also serves as a WPS button, with the click of a button easily and quickly WPS encryption is built (WPA and WPA2 are also supported). The A1 E5180 dominated UPnP (Universal Plug & Play) and is also protected by an integrated firewall.



Connections



For wired Internet connections, the E5180 has only one Ethernet port, here you would already want multiple ports. On the back there are the RJ45 output, the RJ11 port for an analog phone or fax machine as well as the connection for the 12-volt power adapter.



 Availability



The Internet box 4G/LTE E5180 there are offered by A1 for new customers at no extra charge when booking an A1 mobile Internet tariff (S/M/L). If you want the unlocked version of Huawei E5180 A1 Internet box, you can check the online website www.4gltemall.com . We provide international shipping with one year warranty.





Huawei E5377 4G LTE Mobile Hotspot

Huawei adds its router family with a new model E5377, which is a new LTE “pocket-Hotspot” with small size. Here, the Huawei E5377 is not only with fast LTE category 4, but also with its low price points.





Features and characteristics of Huawei E5377

Manufacturer and model

Huawei E5377

Chipset:

HiSilicon B710AM

LTE Category:

CAT4

Download rate up:

Up to 150 MBit/s

Upload rate to:

Up to 50 MBit/s

Supported LTE bands:

800 /850/900/1800/2100/2600 MHz

Backward compatible with:

UMTS; GSM; HSPA+

Support of LTE-Advanced:

No

MIMO Support:

MIMO 2×2

External antenna connector:

yes, 2 TS-9 jacks (Buy Huawei E5377 Antenna)

Category:

LTE modem category 3 (3GPP Release 8)

Telephone

With integrated telephone system:

No

Connector for ISDN telephones:

No

Connection for analog telephones:

No

DECT:

No

integrator answering machine:

No

Network | LAN & WLAN

LAN Ports:

No

WLAN Standards:

Wi-Fi 802.11a / b/g/n (866 Mbit/s)

5 GHz WLAN support:

Yes

Encryption:

WEP, WPA, WPA2

Wireless Internet Hotspot function:

yes – for up to 10 devices

Others

Battery pack:

1500 mAh; interchangeable (to 6 hours of web browsing)

Dimension:

93.5 x 57.1 x 14.4 mm at 82 g

USB:

Micro-USB 2.0

Memory card expansion:

Yes; Micro-SD up to 32GB

Release:

November 2014

available at:

www.4gltemall.com

Technical Features



The Huawei E5377 offers download speeds up to 150 Mbit/s and 50 Mbit/s upload through its LTE Modem category 4, assuming a corresponding LTE tariff. The LTE networks in Germany, Austria and Switzerland are supported on 800, 1,800 and 2,600 MHz. If no LTE available, the router also comes with the mobile radio standards GPRS, UMTS or DC-HSPA+ with speeds of up to 42.2 Mbit/s (download) and 5.7 Mbit/s (upload).





Wireless repeater function

The Wi-Fi standards a/b/g/n is supported on 2.4 and 5 GHz; THE faster Wi-Fi ac is unfortunately not supported. Up to 10 devices can be supplied by Huawei E5377 with wireless Internet, another via USB. In addition, a wireless repeater is integrated into the E5377, which switches automatically from the wireless coverage to a known wireless LAN network when it is available.

HUAWEI E5377 Antenna connectors

Access via browser or app

The hotspot is the smartphone controllable via the Huawei App “Mobile WiFi”, available for both Android and iOS. Access to the web interface of the router is also obtained through a browser. The operating systems Windows XP / Vista / 7/8 / 8.1, Mac OS X will be supported from version 10.7 and Linux.



Informative display

The 1.45-inch TFT LCD display indicates the type, the name and strength of the cellular network, the communication direction (upload / download), the repeater function and battery status, as well as the number of connected devices, the name of the WLAN network, the connection time and the transmitted data volume.



Connector for external antennas

On the bottom of the email, with 9.4 x 5.7 x 1.4 centimeters and very compact with only 82 grams to slight router, two connectors for external UMTS/HSPA+/LTE antennas can be found next to the microUSB port. With matching adapter, SMA antenna can be used to increase the data rate mainly in the house. On the top, the menu button is to get information or make adjustments.

Battery weak, but interchangeable

The Huawei E5377 has a micro SD slot which accepts cards up to 32 GB capacity. The replaceable battery is only 1,500 mAh; and the surf time of up to 6 hours and a standby time (without WLAN) of up to 300 hours. Therefore it’s recommended to carry a spare battery. It comes with only a micro-USB USB cable, but no external power supply adapter – here you have to recharge by connecting it to a PC like smartphones.



Availability

The Huawei E5377 is available in black or white at the online store www.4gltemall.com. If you like this new mobile hotspot, welcome to purchase from 4gltemall.com.

Huawei E5878 Prime 4G LTE Mobile Hotspot

A router looks like a smartphone, and it’s slim like an iPhone, Huawei has presented a new mobile hotspot Huawei Prime E5878 in its product range. The LTE cat4 seems to be the main stream now. Huawei new mobile hotspots all support LTE category 4 or higher LTE standard. So the Huawei Prime E5878 could support peak download speed to 150Mbps and upload speed to 50Mbps. And it could support up to ten devices wirelessly and can be controlled via an app.

Huawei E5878S-32 WITH PC

LTE features and characteristics of Huawei Prime E5878s-32

Manufacturer and type designation

Prime E5878s-32 Mobile WiFi Huawei

Download rate up

150 MBit/s

Upload rate up

50 MBit/s

Compatible LTE Bands

800 MHz / 1800 MHz / 2600 MHz

backward compatible with

UMTS / HSUPA / HSPA+ / GSM / GPRS / EDGE

Support of LTE-Advanced

No

MIMO Support:

MIMO 2×2

Connector for external antenna

No

LTE Category

LTE modem category 4 (CAT4)

Chipset

HiSilicon | Cortex A9 dual-core

Wi-Fi standards

WLAN 802.11b/g/n (up to 300 Mbit/s)

Wireless Internet Hotspot function

yes – for up to 10 devices

Number of LAN ports

no

Others

battery pack

1,900 mAh – not changeable (up to 8 hours surfing)

Dimensions (WxHxD)

58 x 110 x 7.5 mm at 80 g

USB standard

MicroUSB

Memory card expansion

No

Release

Since Q2 2015 trading

available at

»Available at retail

HUAWEI E5878 IN classic black

Technical Features

The Huawei Prime E5878s-32 Mobile WiFi, looks really like a iPhone 4 from the side. With only 7.5 millimeters extremely flat, it can be easily carried in your pocket. The body is integrated in a aluminum enclosure measuring approximately 6 x 11 centimeters. At its 1-inch OLED display, the router displays how many devices are currently connected to him and how much data they consume already – ie sent and received volume. In addition, it shows the received and sent SMS, the battery level, the signal strength and the network used are displayed.



The router has a 128MB of flash memory, as well as an equally large amounts of RAM. A micro SD slot for memory expansion does not exist. And there is a processor HiSilicon Cortex A9 with dual core.

huawei E5878 Front

LTE Cat4 Technology



Equipped with the matching micro-SIM card including data plan allows the Huawei E5878 LTE Prime compounds Category 4 with maximum download speeds of up to 150 Mbit/s and uploads up to 50 Mbit/s. Here the 4G router is backwards compatible with 3G (HSPA+ up to 43 Mbit/s) as well as 2G and has two internal antennas (one on each side of the head of the device) for optimal connection. However, an external antenna can not be connected.



When you have WiFi with standard 802.11b/g/n, it usually takes on 2.4 GHz with up to 300 Mbit/s downstream to be connected. The wireless radio should be 100 meters, with up to ten devices can be connected to the wireless hotspot. The Prime E5878 can be adjusted through a smartphone or tablet.

Huawei E5878 SIM Design

Huawei Mobile WiFi App

When connected to a computer, it supports the operating systems Windows XP, Vista, 7, 8 and 8.1, and Mac OS X 10.7, 10.8 and 10.9. Firmware updates for the device to be supplied by the manufacturer online. Owners of Android smartphones can be downloaded from the Google Play Store, the Huawei Mobile WiFi app and simply connect your smartphone to the router by reading the bar code on the device. With the app, the router can also be controlled via the smart phone as well as further information is obtained.



Through the Micro-USB port, the battery can be charged. With an adapter cable available as an option, a USB-to-Ethernet connection is possible. Push button start, the hotspot is to be operational within 5 seconds. The battery gets to 1,900 mAh, and according to the manufacturer, it should last up to 8 hours of surfing or 380 hours in standby. The capacity would be not enough for surfing, especially since the battery is not replaceable.

huawei E5878 back

Availability

The Huawei prime E5878 is available since Q2 2015 at www.4gltemall.com. It’s a pity that the battery of the E5878 can’t changed and there is connector for external antenna. If you would like a mobile hotspot with replaceable battery and antenna connector, you may try other model such as Huawei E5372 or Huawei E5377.
