Huawei E5885 VS Huawei E5770

You may have known the Huawei Mobile WiFi Pro E5770, as the first generation of Huawei 4G mobile hotspot with Ethernet port and SIM card slot, Huawei E5770 had gained a very good reputation. And now Huawei presented a new upgraded model Huawei E5885, which also has an Ethernet port and SIM card slot. Somebody may ask: What’s the difference between the Huawei E5885 and E5770? What features had been upgraded in E5885? The questions would be answered in this article.

Appearance and Interfaces

Huawei E5770 has a 0.96 inch OLED display on the front to show the internet connection status. Below the display, it’s Huawei logo. The power and WPS buttons are on the top edge side. The Ethernet port and USB input & output ports are covered by a cap. A user needs to open the cap to see the interfaces. The back cover can be opened. Open the back cover, the SIM card slot and SD card slot can be found. On the back cover, it indicates 5200mAh battery. The battery is built-in and non-removable. Unlike other Huawei Mobile WiFi, we can’t find the connectors for external antennas.

Following the design of Huawei E5770, the Huawei E5885 also has a small display on the front to show the connection status. The power button, WPS button, USB ports and Ethernet port are all at the same position like E5770. The difference is that the Huawei E5885 is thicker than the E5770, perhaps because it’s configured with a large battery of 6400mAh, which is shown on the back cover. The Huawei E5770 has black and white colors available while the new Huawei E5885 has the pink & black and black & gold colors.

Specs

From the appearance, we can see the two mobile hotspots are very similar in design. The thickness and colors are different. Then let’s have a look at the comparison of Huawei E5770 specs and Huawei E5885 specs. Since Huawei E5770 has only one variant model E5770S-320 and Huawei E5885 has only one variant model E5885Ls-93a. We will compare the Huawei E5770s-320 and E5885Ls-93a:

Model Huawei E5885Ls-93a Huawei E5770s-320
Product type LTE Mobile Hotspot with Ethernet port LTE Mobile Hotspot with Ethernet port
Category LTE Cat.6 LTE Cat.4
Chipset Hisilicon LTE Cat6 chipset Hisilicon LTE Cat4 chipset
Data rates DL 300Mbps/UL 50Mbps DL 150Mbps/UL 50Mbps
Supported 4G LTE frequency bands * FDD-LTE Band 1/2/3/4/5/7/8/19/20/28
* TDD-LTE: Band 38/40/41/42
* LTE Band 1/3/5/7/8/20/38
WLAN 802.11a/b/g/n/ac, dual-band 2.4GHz & 5GHz 802.11 b/g/n, Single-band 2.4GHz
Max support users 32 users 11 users
MIMO 2 X 2 MIMO N/A
Connector for external antenna No connector No connector
Buy Antenna N/A N/A
App management Huawei Hilink APP 3.0 Huawei Hilink APP
SIM type Micro SIM Standard 6-Pin SIM
Battery Non-removable, 6400mAh Non-removable, 5200mAh
Dimensions  112.00 x 69.20 x 23.00mm 106.0 × 68.4 × 22.5 mm
Ethernet Port On port for WAN/LAN port(RJ-45) On port for WAN/LAN port(RJ-45)
Datasheet download Huawei E5885 Datasheet Huawei E5770s-320 Datasheet
User Manual Huawei E5885 User Manual Huawei E5770 Manual
Other features Power bank, CA, NFC Power bank
Reviews Huawei E5885 Review Huawei E5770s-320 Review
Price 249.00USD 229.00USD



Summary

From the specs table above, we can see the Huawei E5885Ls-93 is more advanced than Huawei E5770s-320. With upgraded Hisilicon LTE Cat.6 chipset, Huawei E5885 could achieve download speed up to 300mbps, which is double faster than that of E5770. With the similar design, the Huawei E5885 seems more fashion than Huawei E5770. And with the large battery of 6400mAh, Huawei E5885 would provide longer working time and make the power bank function stronger than E5770. Huawei E5885Ls-93 could support more LTE frequency bands which are widely available in Americans, Asia, Europe, and Australia, which makes it supports more network providers worldwide. Then it’s no doubt that the Huawei E5885Ls-93a is better than Huawei E5770. With reasonable higher price than that of E5770, we highly recommend the Huawei E5885 Mobile WiFi Pro 2 for your global travel.



Five Huawei Mobile Hotspots with Ethernet Port to Recommend

A few years ago, Huawei presented its first mobile 3G router with Ethernet port Huawei E5151 (In China, it’s called Huawei E5 LAN). Now many mobile hotspots with Ethernet connection are available from many vendors. Today, we would like to review five Huawei mobile hotspots with Ethernet port, including Huawei 3G mobile WiFi hotspot with Ethernet port and Huawei 4G Mobile Hotspots with Ethernet Port.

Huawei E5885

Why people need a 3G/4G hotspot with Ethernet port?

Usually, many people use 3G mobile hotspots or 4G mobile hotspots on the go. The mobile hotspots usually have a SIM card slot, so that users can connect to the hotspot wirelessly. However, if the SIM card signal is not available or only Ethernet connection is available, it’s the show time for the mobile hotspot with Ethernet port. And the business people or somebody who usually travel overseas may face this trouble. In this situation, you may need a 3G/4G LTE hotspot with Ethernet port.



Best Seller – Huawei 3G/4G Mobile Hotspot with Ethernet Port

  1. Huawei E5885 (Also named Huawei Mobile WiFi Pro 2)
  2. Huawei E5770 (Also named Huawei Mobile WiFi Pro)
  3. Huawei E5730
  4. Huawei E5351
  5. Huawei E5151
Huawei E5770 in black and Huawei E5730 in white

From the name, you may don’t know what the difference is between the five mobile hotspots with Ethernet port. The Huawei E5885 and E5770 are two 4G mobile hotspots with Ethernet port while the rest three models(E5730, E5351 and E5151) are 3G mobile hotspots. We make the table below about the specs and features of the five mobile routers for your reference. Let’s see the Huawei 4G mobile hotspots with Ethernet port:

Huawei 4G Mobile Hotspot with Ethernet Port

Model Huawei E5885 Huawei E5770
Product type LTE Mobile Hotspot LTE Mobile Hotspot
Category LTE Cat.6 LTE Cat.4
Data rates DL 300Mbps/UL 50Mbps DL 150Mbps/UL 50Mbps
Supported 4G LTE frequency bands * FDD-LTE: Band 1/2/3/4/5/7/8/19/20/28
* TDD-LTE: Band 38/40/41/42
Band 1/3/5/7/8/20/38
Supported 3G frequency bands B1/B2/B4/B5/B6/B8/B19 850/900/1900/2100MHz
WiFi 802.11a/b/g/n/ac, dual-band 2.4GHz & 5GHz 802.11b/g/n, 2.4GHz
Max support users 32 users 11 users
MIMO 2 X 2 MIMO 2 X 2 MIMO
Connector for external antenna No connector No connector
Ethernet Port Single WAN/LAN port(RJ-45) Single WAN/LAN port(RJ-45)
App management Huawei Hilink APP Huawei Hilink APP
SIM type Micro SIM Micro SIM
Battery Non-removable, 6400mAh Non-removable, 5200mAh
Dimensions  112.00 x 69.20 x 23.00mm 106.0 mm × 68.4 mm × 22.5 mm
USB port Input & Output Input & Output
Datasheet Huawei E5885 Datasheet Huawei E5770 Datasheet
User Manual Huawei E5885 Manual Huawei E5770 Manual
Supported Carriers AT&T, T-mobile, Verizon, Rogers, Telus, Telstra,  Vodafone, Orange, Airtel, MTC, MTN, Vodacom etc.. Including other carriers in Europe, Africa, Middle East, Aisa. Mainly for Europe, Asia, Middle East, Africa, not working well in American areas on 4G/LTE
Review Huawei E5885 Review Huawei E5770 Review
Price/USD 299.00USD 229.00
Huawei E5351

And below is the Huawei 3G Mobile Hotspot with Ethernet Port:

Huawei 3G Mobile Hotspot with Ethernet Port

Model Huawei E5730 Huawei E5351 Huawei E5151
Product type 3G Mobile Hotspot 3G Mobile Hotspot 3G Mobile Hotspot
Data rates DL 42Mbps/UL 5.76Mbps DL 42Mbps/UL 5.76Mbps DL 21Mbps/UL 5.76Mbps
Supported 4G LTE frequency bands n/a n/a n/a
Supported 3G frequency bands 900/2100MHz 900/2100MHz 900/2100MHz
WiFi 802.11b/g/n, 2.4GHz 802.11b/g/n, 2.4GHz 802.11b/g/n, 2.4GHz
Max support users 10 users 10 users 10 users
MIMO n/a n/a n/a
Connector for external antenna No connector No connector No connector
Ethernet Port Single WAN/LAN port(RJ-45) Single WAN/LAN port(RJ-45) Single WAN/LAN port(RJ-45)
App management Huawei Hilink APP Huawei Hilink APP Huawei Hilink APP
SIM type Standard SIM Standard SIM Standard SIM
Battery Non-removable, 5200mAh Removable, 1500mAh Removable, 1500mAh
Dimensions 99.0mm×66.3mm×22.5mm 92.8mm x 63.5mm x 16.3mm 92.8mm x 63.5mm x 16.3mm
USB port Input & Output Input Input
Datasheet Huawei E5730 Datasheet Huawei E5351 Datasheet Huawei E5151 Datasheet
User Manual Huawei E5730 Manual Huawei E5351 Manual Huawei E5151 Manual
Supported Carriers Mainly for Europe, Asia, Middle East, Africa, not working well in American areas on 4G/LTE Mainly for Europe, Asia, Middle East, Africa, not working well in American areas on 4G/LTE Mainly for Europe, Asia, Middle East, Africa, not working well in American areas on 4G/LTE
Review Huawei E5730 Review Huawei E5351 Review Huawei E5151 Review
Price/USD 148.00 139.00 139.00
HUAWEI E5151 Ethernet port
Huawei E5151

They are the best sellers of Huawei Mobile Hotspots with Ethernet port. The Ethernet Port in the devices is for WAN & LAN. Here now, there are many mobile hotspots with Ethernet from other manufacturers, but some of them are only for LAN, not for WAN, which means you can only connect to the network via 4G SIM card. You cannot connect to WLAN network via Ethernet port.



The above mobile hotspots with Ethernet port support LTE to LTE-A networks, and 3G mobile hotspots available. You may find one for yourself if you have demand for such functions. And we have to mention that the large battery capacity in the Huawei E5885, E5770, and E5730, which can also charge other devices such as smartphones, gadgets etc…This could also be praised for the practical function.

Huawei Mobile WIFI PRO 2 E5885 Review

Last year, Huawei released a new version of the Mobile WiFi PRO to replace the predecessor model Huawei E5770 and simply names it Mobile WiFi PRO 2. The specific model number of the Mobile WiFi Pro 2 is Huawei E5885.

This new version Mobile WiFi Pro 2 mainly brings 4G LTE Category 6 with a theoretical data rate of 300 Mbps for download and 50 Mbps for upload. Also at the WLAN feature, dual band WiFi bands are available with providing WiFi 802.11ac.

The most important feature is an increase in battery capacity from 5200mAh to 6400 mAh and is offered the ability to charge other devices via its full-size USB port (in addition, it also has a microUSB charging port). Of course, the RJ 45 Ethernet port and the 0.96 inch OLED display are retained. Huawei E5885 is the first LTE Cat6 portable 4G router with Ethernet port. Currently, there is only the Netgear Nighthawk M1 which supports higher-level LTE standard with Ethernet port and could be its competitor.

The improvements of Huawei E5885 are not only on the WLAN features, battery capacity, it can also covers the most popular LTE frequency bands in American areas, such as LTE Band 4(AWS).

Comparing with its predecessor, Huawei Mobile WiFi Pro 2 can support wireless users from 11 to 32, which is the norm qty today.

The Mobile WiFi PRO 2 can let devices to connect WiFi by NFC technology or scanning the QR code QR. The Huawei HiLink APP is also useful for users to do some further settings if necessary. And we have to mention the special feature: the strap used as USB charging cable.



The Huawei E5885 Mobile WiFi Pro 2 is compatible with the common LTE frequency bands in Europe and America, so users can take this device and travel to these areas without worrying the network incompatibility.

Here now, the Huawei Mobile WIFI PRO 2 has been launched in China at a price of around 200USD, it will take patience to price down since it’s a powerful mobile pocket WiFi with Ethernet and large battery capacity. And 2 colors will be available: Black and Gold & Pink and Gold.

Below is the general review of the Huawei E5885 Mobile WiFi pro 2 Specs:

* WIFI AC (802.11ac) compatible b/g/n

* Number of users connected simultaneously: up to 32 Devices

* WMM (WiFi multimedia) / media server feature: Yes

* Beamforming / MultiBeam feature: Yes

* uPNP (universal plug and play): Yes

* Frequency range Dual Band (2.4 GHz / 5 GHz)

* Speed ​​download: up to 300 Mbps

* Special features Cat6 – 300 Mbps, HiSilicon LTE Cat6 Chipset

* Guest network access: Yes

* Number of ethernet port (RJ-45): Single Port (LAN) / RJ-45

* Cards supported Micro SD / Micro SDHC / Micro SDXC

* Color: Black

* SIM type: Micro SIM

* LED Indicator Strength Signal / Network / Charging / Provider / WiFi / SMS

* Number of antenna: unknow

* Security features Encryption (WEP / WPA-PSK / WPA2-PSK)

* WPS (WiFi protected set-up) : Yes

* Power source Lithium-ion battery battery (Li-Ion): Battery capacity 6400 mAh

* Dimensions: 23 mm X 69.20 mm X 112 mm

* Weight: 188 g





Huawei Mobile WiFi Pro 2 Released

Huawei had released a new 4G LTE Mobile WiFi a few days ago in Suadi Arabia, named Mobile WiFi Pro 2, which is to replace the current Mobile WiFi Pro E5770 on the market. As a 4G pocket router with practical functions, Huawei Mobile WiFi Pro 2 comes too later than that we expected.



Like its predecessor Huawei E5770, the Huawei Mobile WiFi Pro 2 combines the pocket router and power bank function into one device. It can not only provide wireless network through WiFi & Ethernet cable for high-speed internet connection, but also charge other electrical devices.



Appearance



Huawei Mobile WiFi Pro 2 upper surface features a high-definition OLED screen with a 0.96 inch diameter. And it is decorated with artistic patterns and a unique contrast in the used materials, while maintaining a user-friendly operating button. The Mobile WiFi Pro 2 uses a metal frame in the middle and also provides a stylish leather handle that caters to the tastes of users and provides the port for charging smart devices and for Ethernet cable. There is also Micro-SIM card slot and extra slot for Micro SD card of up to 32GB.

LTE Advanced (Cat.6) Support

With Huawei Hisilicon LTE Cat6 chipset, Huawei Mobile WiFi Pro 2 could support LTE-Advanced networks on LTE Category 6, which means it could achieve peak download speed to 300mbps and upload speed to 50Mbps on LTE networks. The speeds are almost double of that of the first generation Huawei Mobile WiFi E5770 on LTE Cat.4 networks. Of course, they are both backward with 3G UMTS/DC-HSPA+ and 2G GSM, which would be available once LTE network is missed.



WLAN Improvement

Huawei also improved the wireless function for Mobile WiFi pro 2 to support maximum up to 32 WiFi-enabled devices, while the Huawei E5770 Mobile WiFi Pro supports only 11 users simultaneously. The WLAN features 802.11a/b/g/n/ac on dual-band 2.4GHz and 5GHz, but the Huawei E5770 had missed the ac standard and had only single band WiFi.

Large Battery Capacity of 6400mAh

The battery of Huawei Mobile WiFi Pro 2 is 6400mAh, it’s totally a common mobile power bank which can not only keep itself working for long time and also charge other terminals such as smartphones, Pads in case of power off. However, the capacity of 6400mAh may not be the best, because we know Huawei also had one Mobile WiFi named Huawei E5771 Mobile WiFi Plus, which has the large battery to 9600mAh. And other features are very similar to E5770.



Easy Connection without password

By using Huawei Mobile WiFi Pro 2, a connection can be established and devices can be identified using NFC technology or QR code and Huawei’s application HiLink without the need to search for the network and enter password to join the Wi-Fi network.



Here now, the Huawei Mobile WiFi Pro 2 is not yet available on the market, but we are keen to get this new 4G pocket router. We will show the test report once we get it. You can also keep close eye on www.4gltemall.com to get new information about Huawei Mobile WiFi Pro 2 and other 4G mobile broadband.





Huawei E5573 Mini MiFi Router Overview

Now Huawei obviously focuses more on the development of mobile hotspot routers, as well as new LTE sticks. The small devices are a little larger than sticks, but far more diverse. So there are many products of mixture of router and stick. And now we get the E5573s, Huawei provides another device for mobile and stationary use. Find out what the Huawei E5573 offers.

Huawei E5573

Features and Specifications of Huawei E5573
Manufacturer and Model Number: Huawei E5573s-320
LTE Category: LTE CAT4
Download rate up: 150 MBit/s
Upload rate to: 50 Mbit/s
Supported LTE bands: LTE Band 1/3/5/7/8/20  (800/900/1800/2100/2600MHz)
Backward compatible with: HSPA+, HSUPA, UMTS, Edge
Support of LTE-Advanced: No
MIMO Support: 2 x2
External Antenna: Yes, Dual TS-9 connectors (Buy Huawei E5573 External 4G antenna)
Network | LAN & WLAN
LAN ports: no
WLAN standards: 802.11a/b/g/n
5 GHz WLAN support: YES
encryption: WEP, WPA, WPA2
Wireless Hotspot function: Yes, up to 10 devices
Others
SIM type Mini SIM
Battery pack: 2300mAh (operation to 6h; standby to 300h)
Dimensions (WxHxD): 96.8 x 58 x 12.8 mm at 75 grams
USB: Micro USB
Memory card expansion: No
release: mid-2015
available at: WWW.4GLTEMALL.COM



 Huawei E5573

LTE Technologies



The Huawei E5573s supports LTE Category 4 (CAT4), which is sufficient for most customers. The LTE module in Huawei E5573 could provide download rates up to 150 Mbps in LTE network. In addition, if the LTE network is not available, the operating via HSPA+, HSUPA, UMTS (3G) and Edge (2G) is possible. As a global model, the Huawei E5573 could support TDD-LTE/FDD-LTE/WCDMA/UMTS/GSM networks. Here we have the Huawei E5573s-320 supports 4G FDD-LTE Band 1/3/5/7/8/20 (800, 850, 900, 1800, 2100 and 2600 MHz). Actually, there are many variant models for Huawei E5573, below are the sub-models listed with the supports network frequency bands:



Huawei E5573s-320:

– FDD Band 1/3/5/7/8/20 (800/850/900/1800/2100/2600MHz)

– WCDMA Band 850/900/2100MHz



Huawei E5573s-856 (For China Unicom):

– TDD Band 40/41

– FDD Band 1/3

– WCDMA Band 1/8



Huawei E5573s-852 (For China Mobile):

– TDD LTE Band 38/39/40/41

– FDD LTE Band 3/7

– TD-SCDMA B34/39



Huawei E5573s-606:

– LTE-FDD 2600(7)/2100(1)/1800(B3)/700(B28)MHZ

– LTE-TDD Band 40 (2300MHz)

– DC-HSPA+/HSPA+/HSPA/UMTS 2100/900/850 MHz



Huawei E5573s-607:

– FDD Band 5 (850MHz) & TDD Band 40 (2300MHz)



Huawei E5573s-156(also MTS 8210FT):

– LTE-FDD 1800(3)/2600(B7)/800(B20)MHZ

– LTE-TDD Band 38 (2600MHz)

– DC-HSPA+/HSPA+/HSPA/UMTS 2100/900/850 MHz



Huawei E5573s-508:

– LTE-FDD 1700(4)/2600(B7)/700(B13)MHZ

Huawei E5573

From the above frequency bands, users can choose the appropriate one for their market per the carriers at their locations or countries. If you would take the E5573 MiFi for oversea travel or use in multiple countries, you would better to clarify the network frequency bands of the destination countries and find the correct variant model.



Wireless Features

The Huawei E5573 4G hotspot router allows the connection of up to 10 additional devices, such as smartphone, laptop, tablet or game console. It supports the 802.11a/b/g/n. The modern wireless ac is not integrated again, which we find quite a pity.

Huawei E5573



External antenna

Like other Huawei 4G mobile hotspots, the Huawei E5573 has two TS-9 jacks for connecting an external LTE antenna. Thus, if the E5573 is used in areas with difficult reception conditions, the signal can be improved by connecting a 4G antenna. Here we have one smart antenna for Huawei E5573 to recommend: http://www.4gltemall.com/4g-antenna-two-ts-9-connector.html

4G LTE Indoor Antenna (2 x TS-9 Connectors) for Huawei/ZTE 4G LTE Modems/dongles/mobile hotspots



Battery

One important matter for a mobile router of course is still the battery. The Huawei E5573 has a capacity of 2300 mAh for about 6 hours of operation and 300 hours standby which is enough according to the manufacturer. In practice, you may found the battery is not really enough on intensive use. In this case, the similar model Huawei E5770 Mobile WiFi Pro or Huawei E5771 WiFi Plus may be better options because they have large power capacity for much longer working time.

Huawei E5573

Conclusion





Currently the Huawei E5573 is available on www.4gltemall.com. You can check the variants for different areas. And 4gltemall.com could ship the Huawei E5573 to anywhere of the world. It’s easy to get this pocket WiFi. Since the Huawei E5573 technically hardly differs from devices such as the Huawei E5577, it is still a good mobile WiFi Router.



ZTE MF903 4G Pocket WiFi Review

Following the steps of the competitor Huawei, the Chinese Telecom equipment vendor presents a new 4G Mobile WiFi Hotspot named ZTE MF903, which is very similar to Huawei Mobile Wifi Pro E5770. The Huawei E5770 mobile hotspot was proved to be a powerful portable 4G router with multi-functions. And ZTE MF903 copied almost all the features and comes to be a budget option for users.

ZTE MF903 LED indicators

The appearance of ZTE MF903 is not like E5770, which has a small screen to show full connection status when working. The MF903 has only a few indicators about battery, WiFi, message and signal. The left side of the indicator is ZTE logo and the right side is power button.



If you had read our introduction of Huawei E5770 hotspot, you may know the interfaces/ports are covered by a small tap, under which there are there ports for Ethernet cable, USB in and out. (If you want to know more about Huawei E5770, click here.)This design could protect the ports form dust. But the ports are open to air in ZTE MF903 hotspot.  The lucky thing is the Sim and SD card slots are protected by a cover.  The reset hole is at the side of SD card slot.

ZTE MF903 interfaces

ZTE MF903 is using ZX297520 while Huawei E5770 is based on Huawei Hisilicon chipset. Both of them can provide same functions. They can transfer the 4G wireless network from a SIM card to WiFi signal so that the connected devices via WiFi could access internet. This can make true of when user insert SIM cards to them. But if users connect an Ethernet cable to them, they can also transfer the network from Ethernet to WiFi, after connected with the WiFi, user can also surf freely.  The only difference on this is that Huawei E5770 could support up to 11 users while MF903 support only 8 devices.

ZTE MF903 charge smartphone

The shinning point of the two mobile hotspots is the large battery capacity, which would not only keep themselves long-time working but also charge other electronic devices such as mobile phones, tablets, game terminals etc..

ZTE MF903 SIM and SD card slot

Regarding the technical specifications, ZTE MF903 and Huawei E5770 both support the LTE category 4 technology and could achieve download speed to 150Mbps and upload speed to 50Mbps. Both can work well on TD-LTE and FDD-LTE networks but it depends on the specific model number. And the download and upload speeds are theoretical under perfect environment, in practice, the speed can’t reach these speed due to network congestion or far distance to the cell tower. But they can also work on UMTS network if 4G LTE network is not available. What’s more, they both can be controlled by APP. For ZTE MF903 to use ZTELink while for Huawei E5770 to use Huawei mobile WiFi app. User can also manage the settings through web UI in the browsers.

ZTE MF903 back label

From the appearance and technical features, we can’t tell which one is better. But we think the Huawei E5770 would be at higher price than ZTE MF903 due to the Huawei’s brand reputation and quality trust from customers. We will do a network connection test next to see which one is better in performance.

Huawei E5351 3G 42Mbps Mobile WiFi Hotspot Review

We had introduced the Huawei E5151 pocket WiFi years ago, which is a 3G mobile WiFi router supporting download speed to 21Mbps and the most important feature of this pocket WiFi is that the E5151 has a port for LAN/WAN, which could connect with an Ethernet cable to get or share internet connection. At that time, some customers were wondering if there is newer model which could support higher speed connection, i.e. download speed is faster than 21Mbps.

Huawei E5351 E5351s-2

Actually, we had introduced the latest Huawei E5770 mobile WiFi Pro, which has LAN/WAN ports and supports download speed to 150Mbps on LTE Category 4 technology. And the Huawei E5770 has large battery of 5200mAh, which not only keeps itself long time working, but also works like a mobile power bank to charge other electronics such as smartphone or tablets. However, many customers said the price of Huawei E5770 is a little bit high; it’s not a budget pocket router. Really, it’s a high-end partner for wireless connection.

Huawei E5351 E5351s-2

Today, we will introduce another new mobile pocket router. The model number is Huawei E5351. It’s still a 3G mobile router and upgraded from huawei E5151 MiFi. From the appearance, we can see the Huawei E5351 is very similar to Huawei E5151, they both have a port for an Ethernet cable and USB interface. The LED indicators on the front and back logs are almost the same.

Huawei E5351 E5351s-2



The battery capacity of E5351 MiFi is still the same to E5151, only 1500mAh. For most users, it’s not enough for common use. The lucky thing is the battery can be removable, so if there is a spare battery or mobile power bank, it would be OK to use for long time. From this point, we would recommend the Huawei E5770 with large battery; users don’t worry about the power off when working with E5770.

Huawei E5351 E5351s-2

The key features of Huawei E5351 are listed below (same to E5151):

  1. Provide wireless internet connection through WiFi from the Ethernet cable
  2. Provide wireless internet connection through WiFi from the inserted SIM card
  3. Provide internet connection through Ethernet cable from inserted SIM card



The SIM card slot of Huawei E5351 is for a standard 6-pin SIM card, which is the same to E5151. But there is no slot for Micro SD card. The most important features should be the improvement of the wireless data transmission speed. Huawei E5351 could support almost double speed of that of E5151. With 3G DC-HSPA+ technology, Huawei E5351 could achieve peak download speed to 42Mbps while E5151 only support speed to 21Mbps. Like E5151, up to 10 wireless devices could access internet through Huawei E5351.

Huawei E5351 E5351s-2

In all, Huawei E5351 is a powerful mobile pocket router for traveling or business trip. It provides more option for wireless internet connection. But if you don’t need the LAN port, you may try other budget Huawei mobile WiFi hotspots options such as Huawei E587 or E5730s, which has good performance for internet connection.

Difference Between Huawei E5770 and E5730s

In the market of network equipment, Huawei is always one of the most influential companies. We can see the clear demonstration of how the world is evolving on vendor network equipment on two mobile routers: First one is the snow white Huawei E5730 and the other one Huawei Mobile WiFi Pro E5770 showed at the MWC 2015 in Barcelona. Somebody may ask what’s the difference them. The list below shows some basic difference between them:

Model

Huawei E5730s

Huawei E5770

Type 3G Mobile Hotspot 4G LTE Mobile Hotspot
Network DC-HSPA+/UMTS/HSPA TDD-LTE/FDD-LTE/DC-HSPA+/UMTS/HSPA
Data Rate DL 42Mbps/UL 5.76Mbps DL 150Mbps/UL 50Mbps
WLAN 802.11 b/g/n 2.4 GHz 802.11 b/g/n 2.4 GHz
Battery 5200mAh 5200mAh
Dimensions 99.0mm×66.3mm×22.5mm 106.0 mm × 68.4 mm × 22.5 mm


It’s no doubt that the RJ 45 port on the Huawei E5770 and E5730 is the top shinning feature. It provides much more possibility of network solution for user. Secondly, the large power capacity is also practical function for most users. As a mobile hotspot, they have the backup functions which can make users have great experience. Actually, they are similar and different at the same time: the power output and input ports and Ethernet port are both at the side. The ports on Huawei Mobile WiFi Pro E5770 are covered by a cap, so users have to open the cap and see all the ports. The Huawei E5730 is in white while the E5770 has two colors: white and black.

The boy difference is also obvious: Huawei E5730 has only one power button on the front, while Huawei E5770 has LED screen on the front. On the display, user can see the battery status, network status, SSID and password, connected WiFi users. The battery capacity of 5200mAh is printed on the back of Huawei E5770, but at the body side of E5730.

Huawei E5770 is a little bit thinner than E5730. The batteries in the two devices are both non-removable. But the back cover could be opened and the SIM card slot is there. Huawei E5770 has one SD card slot, but E5730 has no SD card slot. And there is stick besides the SIM card slot. It shows the model number, IMEI number, S/N number, SSID, WiFi password and QR-code to download Huawei Mobile WiFi APP.

The most attractive and important feature for them is the supported networks. Upgraded from Huawei E5730, Huawei E5770 could support peak download speed to 150mbps based on LTE Category 4 chipset. The upload speed could reach 50mbps. E5730 can’t reach the speed but as a 3G mobile hotspot, it’s almost one of the best 3G routers based on its specifications. When Huawei E5730 was on sales, somebody is asking: when can i buy the 4G version of Huawei E5730 with RJ45 port? Now Huawei Mobile WiFi Pro E5770 is available. This the version for 4G pocket router with RJ45. So if you like it, it’s time to get one.

Huawei E5770 Mobile WiFi Pro Review

Huawei new 4G Mobile WiFi hotspots always give great surprise to us. The new 4G pocket router Huawei E5770 Mobile WiFi Pro fills a gap in the extensive range of Huawei router: the unit combines a powerful LTE modem with a RJ-45 LAN port and a strong 5.200 mAh battery. In March 2015, the LTE mobile router was on the occasion of the Mobile World Congress presented in Barcelona, now the device is also available in many countries. With a small display on the front and a WiFi Extender function, the Huawei E5770 could register into existing wireless networks in order to use these as Internet access.

Appearance

The Huawei E5770 Mobile WiFi Pro comes in a turquoise cardboard box. In the package, there is a PSU with USB port, a microUSB charging cable and a Quick Start Guide and safety information. At first glance, the Huawei E5770 looks quite large with 200 grams, at least in comparison with other mobile LTE hotspots such as the Huawei E5377. This is mainly due to the exceptionally strong battery that is not replaceable by the way. The Huawei E5770 is manufactured in black or white and completely made of plastic. The following are the technical data in the overview:



Model Huawei E5770s-320
Product type LTE Mobile Hotspot with Ethernet port
Category LTE Cat.4
Chipset Hisilicon LTE Cat4 chipset
Data rates DL 150Mbps/UL 50Mbps
Supported 4G LTE frequency bands * LTE Band 1/3/5/7/8/20/38
WLAN 802.11 b/g/n, Single-band 2.4GHz
Max support users 11 users
MIMO N/A
Connector for external antenna No connector
Buy Antenna N/A
App management Huawei Hilink APP
SIM type Standard 6-Pin SIM
Battery Non-removable, 5200mAh
Dimensions 106.0 × 68.4 × 22.5 mm
Ethernet Port On port for WAN/LAN port(RJ-45)
Datasheet download Huawei E5770s-320 Datasheet
User Manual Huawei E5770 Manual
Other features Power bank
Firmware download Huawei E5770 Firmware
Drivers Huawei E5770 Driver
Price 229.00USD



Operation & Software

The operation of the Huawei E5770 is very simple. The SIM card must be plugged like an optional memory card under the removable rear panel. There you can find the activated WLAN password, and the address for the Web Interface and the password required for this. The SIM card is inserted together with the MicroSD card on the back. The operation and configuration via the web interface is quick and easily, both on desktop computers and on Tablet touchscreen. On the start screen, the consumed data volume and online time is displayed, on request you can have a look at detailed statistics or tariff limits deposit. It is also possible to receive and send SMS. Navigate to the tab “Settings”; you can set your machine accurately, about the wireless connection or the RJ45 Ethernet connection.

WLAN and Ethernet

The Huawei E5770 Mobile WiFi Pro offers three ways to access the Internet. First of course there’s the classic access via the mobile network so that up to 150 MBit/s accessible via LTE Cat4. Then you can also use the RJ45 Ethernet port as Internet access, which offers network connection at home, office or hotel. The third way to access the Internet is the so-called Wi-Fi Extender: the Huawei E5770 thus uses an existing wireless network to access internet.



All three types of access have worked well and without any problems in the test. Particularly interesting is the WiFi Extender function, because then it is also possible to connect multiple devices to a wireless network. As soon as the wireless network, the Huawei E5770 automatically switches from LTE to Wi-Fi access. Huawei E5770 could support up to 11 devices simultaneously. In LTE network, the Huawei E5770 Mobile WiFi Pro Router provides a good reception and many supported frequency ranges, so that it can also be used abroad in many countries. Huawei E5770 would support LTE Advanced Cat4 and the LTE modem Cat4 could achieve 140Mbit/s in the test. It’s a pity that it can’t support LTE CAT6, also disappointed that Huawei mobile WiFi Pro doesn’t have connections for an external antenna.

Battery and More

With the amazing 5,200 mAh strong battery, the Huawei E5770 Mobile WiFi may be used up to 20 hours per operating as a mobile LTE hotspot. The full-size USB port allows charging other devices such as smartphones or tablets. Through the output of 5V / 2A, the charging goes very quickly. The battery capacity is proudly advertised. But the battery can’t be removed. Finally, a little word to the display on the front of the Huawei E5770: this is definitely smaller than many other mobile wireless hotspots of Huawei, but it does the job properly and provides all important information such as data usage and battery status clearly. With a short press on the power button, you can see the wireless password in screen.

Conclusion: A perfect solution for Travel

The Huawei E5770 is a good mobile LTE router with two great unique features: it is the first device of its kind with RJ-45 LAN port and simultaneous support for LTE and it is one of the few devices, which simultaneously can also be used as a power bank for charging other devices. Overall, the router can convince definitely, besides the classic functions of the wireless Extender function should be emphasized. But there are three drawbacks: the missing of 5GHz WLAN and connections for an external antenna, and the feature of LTE Cat6 with 300 Mbit/s is not supported. Even though, the Huawei E5770 Mobile WiFi Pro is still a wonderful pocket WiFi router!

If you want the LTE cat6 mobile wifi, huawei E5786 may help you.

Huawei Mobile WiFi Pro E5770 Review

When we got the Huawei E5730s mobile WLAN router last year, some customers ask when we can get the 4G device like Huawei E5730s. Now we get the new one with Ethernet port, the model number is Huawei E5770. Huawei named it “Huawei Mobile WiFi Pro”. If you know Huawei E5730s, you may know the similar functions of Huawei E5770.

Huawei Mobile WiFi Pro is the upgraded model from Huawei E5730S. It supports 4G networks while E5730 only supports 3G networks. The design of Huawei E5770 looks cool. The wallet design of the Mobile WiFi Pro is fashioned with a leather texture and ornamental plating mid-frame. The E5770 is compact enough to fit in a pocket, and it’s also been fitted with an array of built-in innovations.

Like other Huawei 4G mobile WiFi, there is a 0.96 OLED screen on the top front, which can show the network mode, network strength, SMS, battery status and consumed data. Beside the screen, the Huawei logo is printed. On the top side, there is a cover beside the screen. Open the cover, we can see the USB input and output port. And there is an Ethernet port. The USB input is to charge the Mobile WiFi Pro. And the USB output is to charge other electronics.



Huawei E5770 is designed with protected and hidden ports, and is also built with Ethernet/3G dual link and the flexibility to support WAN/LAN auto redirect – all so you can stay connected without any problems while you travel. The Ethernet port is the key feature of Huawei Mobile WiFi Pro. Through the Ethernet port, Huawei E5770 can finish three functions:

  1. Transfer the internet connection to WiFi
  2. Transfer 4G connection from SIM to WiFi
  3. Transfer 4G connection from SIM to Ethernet connection

What’s more, Huawei E5770 could support peak download speed to 150mbps on 4G LTE networks. The upload speed could also reach 50Mbps. To have better internet connection speed, Huawei E5770 mobile WiFi Pro should soon replace Huawei E5730s. It would be a perfect partner for international travel on 4G.



Another key feature of Huawei mobile WiFi Pro is the battery. The battery has a capacity of 5200mAh, which is much larger than usual smartphones. So the Huawei E5770 can be seen as a mobile power bank for other mobile terminals such as mobile phones, tablets or iPods. It can work effortlessly up to 20 hours straight and standby for over 500 hours.

Like other Huawei E5 Mobile hotspot, Huawei E5770 could support up to 10 wireless devices to access internet. User can insert a micro SD card to 32GB. Mobile WiFi Pro’s big storage means it’s now easier than ever to share files between your devices. It helps you quickly and easily “share” photos, apps with your friends through the same mobile Wi-Fi.



To sum up, Huawei E5770 combines 3 main functions (Mobile hotspot, power bank, Ethernt router) to one. It’s a special and very practical mobile pocket router. If you usually need wireless network outdoor, Huawei Mobile WiFi Pro E5770 would be a perfect partner.
