Uros Goodspeed ZTE MF900 LTE Mobile Hotspot

For many devices, it has become a must to have access to the Internet abroad. It may be due to that one wants to share his vacation photos via Facebook or Instagram with friends, or that you have to work as a business traveler outside his hotel with the laptop.  The Finnish company Uros offers with their mobile hotspot Goodspeed MF900 on a solution that now dominates LTE.

Features and Specifications of Uros Goodspeed MF900

Manufacturer and Model Number

ZTE MF900 (Uros Goodspeed)

Chipset:

Qualcomm MDM9225 Gobi

LTE Category:

CAT4

Download rate

Up to 150 Mbit/s

Upload rate

Up to 50 Mbit/s

supported LTE bands:

850/900/1700/1800/1900/2100/2600 Mhz

backward compatible with:

DC-HSPA+ / UMTS / GSM

Support of LTE-Advanced:

no

MIMO Support:

WLAN MIMO

External antenna connector:

no

Network | LAN & WLAN

LAN Ports:

no

WLAN Standards:

WiFi 802.11 b/g/n

5 GHz WLAN support:

yes (5.8GHz)

Encryption:

WPA, WPA2

Wireless Internet Hotspot function:

Yes, for up to 14 devices

Others

Battery pack:

3,200 mAh

Dimensions:

123 x 62 x 14 mm

USB:

MicroUSB

Memory card expansion:

no

available at:

www.4gltemall.com





Technical Features



The previous Hotspot sold by Uros could offer a maximum 3G speed. The new model MF900, which is offered from July, is produced by ZTE and has a Qualcomm chipset (MDM9225 Gobi), which has an LTE module of category 4. The download speed to a maximum of 150 Mbit/s and upload speed to 50 Mbit/s could be achieved, of course only where a LTE network is available. It supports most 7 LTE bands. The Hotspot produces a wireless b/g/n network  to 2.4 and 5.8 GHz, in which up to 14 mobile devices such as tablets, smartphones or laptops can dial in order to surf the Internet.





Display & Battery



The ZTE MF900 hotspot, which comes in the design of a smartphone and pocket fit with 125 grams, has a small display that can display the name of the used mobile network, the number of connected devices, the used data volume and the battery level. In addition, the name and password of the generated Wi-Fi network can be displayed in order to make it available to other users. The strong battery of MF900 is 3,200 mAh and can take 12 hours active use time or 7 days standby time, which is approximately the same length as a smartphone.



Support for up to 10 SIM cards



10 SIM card slots are available, each 5 are on each side: Taking the front panel of the instrument, shows the unique selling point of the Goodspeed router. If you use the Goodspeed MF900 Hotspot in other countries, the hotspot automatically switches to the local network mode to support the available network, so you have to worry about anything.





77 countries worldwide



Uros offers SIM cards for 77 countries worldwide (Jul. 2015). Europe is expected to be already well covered with more than 30 countries. In Asia and in the Americas, more than a dozen countries are supported, including the US and Canada, Argentina and Brazil, Japan and Thailand. According to the provider, the number of available countries will be further expanded. Through a partnership with Vodafone, Turkey, Romania, Malta, Albania and seven African countries are added, including South Africa.



Availability & Price



The Uros Goodspeed 4G Mobile Hotspot is now available on the shop www.4gltemall.com, you can buy at a fixed price right in the shop. But you have to buy a contract from the network provider. 4gltemall.com only provides the devices, the contract SIM is not available with the device.



Huawei E5373 4G LTE Router

The Huawei E5373 is an affordable mobile LTE router with integrated battery and WLAN hotspot feature. The integrated modem in E5373 can reach speeds of up to 150 megabits per second in the LTE network. Instead of expensive extras such as a display installed on the front, the manufacturer has focuses on the essentials about integrated dual-band Wi-Fi. In the following information sheet, you will find all the details for Huawei E5373.





Features and specifications of Huawei E5373 router
Manufacturer and model Huawei E5373
Chipset: HiSilicon
LTE Category: LTE modem category 4 (3GPP Release 9)
Download rate Up to 150 MBit/s
Upload rate Up to 50 MBit/s
Supported LTE bands: LTE800, LTE900, LTE1800, LTE2100, LTE2600
Backward compatible with: DC-HSPA+, UMTS, GSM (UMTS 900 and 2100MHz )
Support of LTE-Advanced: no
MIMO Support: MIMO 2×2
External antenna connector:

Yes; 2 antenna connectors available(buy Huawei E5373 antenna)

Network | LAN & WLAN
LAN Ports: no
WLAN Standards: 802.11a/b/g/n
5 GHz WLAN support: no
Encryption: WPS/WPA/WPA2
WiFi Extender function: no

Wireless Internet Hotspot function:

Yes, up to 10 devices
Others
Battery 1500 mAh (6 hours)
Dimensions: 93 x 57 x 13 mm at 82 grams
USB: 1x Micro USB 2.0
Memory card expansion: Micro-SIM card slot (up to 32GB)
Release: about August 2015
available at: www.4gltemall.com

LTE Cat4 and DC-HSPA+



The centerpiece of the Huawei E5373 is a cellular modem HiSilicon, a subsidiary of manufacturer Huawei. The modem supports all important for Europe frequency bands and allows data rates of up to 150 Mbit/s downstream and 50 Mbit/s upstream depending on the network. In practice, however, the rate could usually be well below the maximum. If LTE network is unavailable, the modem supports both GSM and UMTS networks, the two older wireless technologies. In the UMTS network, it also allows up to 42.2 Mbit s download and 5.76 Mbit/s upload speed if the data accelerator DC-HSPA+ are used.



On the body side of Huawei E5373, you can find two connections for an external antenna. The connector type is TS-9. When the device is in low data rates or unstable Internet connection, an external antenna is recommended. The two connectors are hidden under a cover.



Dual Band WLAN

Up to 10 units can connect to the E5373 LTE router simultaneously via WLAN. Another device may also take advantage of the Internet connection via the microUSB connector and the cable supplied. The manufacturer Huawei has opted for a module, which can send and receive both at 2.4 GHz and 5 GHz. The 5 GHz band is particularly useful when the frequency range is overloaded on 2.4 GHz, which may often happen on large-scale events or in a residential area with many local residents.



6 hours operating time

The Huawei E5373 has a battery with a capacity of 1500 mAh. The energy storage unit is easily replaceable by the user, so if necessary, you can buy a second battery to extend the operating time. According to Huawei, one can expect a runtime of up to 6 hours of continuous operation, then the battery needs to be charged through the microUSB connector again.



Availability and price

Now the Huawei E5373 is available on www.4gltemall.com .The price is in budget without a contract. In the mobile operators in Germany, Austria and Switzerland, the LTE router is not available, so you should look around when necessary for a separate data plan with a provider of their choice. Huawei E5373 can work well with almost all network provides in Europe, if you usually travel or go outdoor, it’s a good partner!

Alcatel One Touch Link Y900 LED Review

Ten years ago, EDGE speed of 400 kbit/s seemed to be the recklessness, but today no surprise on even the possibility of mobile Full HD video. Technology does not lag behind the growing demand: the standard LTE-Advanced is already implemented, allowing you to transfer data twice as fast compared to conventional LTE. One of the best devices the newest standard router Alcatel One Touch Link Y900, which will be discussed in this review.

Alcatel One Touch Link Y900 Specifications

* Technology:

– GSM 850/900/1800/1900 MHz

– UMTS 850/900/1900/2100 MHz

– LTE Band 1,3,7,8,20(800/900/1800/2100/2600MHz)

* SIM: micro-SIM

* Wireless interfaces: Wi-Fi 802.11a/b/g/n/ac

* Support Memory Card: microSDHC up to 32 GB

* Battery: 3600 mAh removable

* Dimensions: 89 x 62 x 16,6 mm

* Weight: 125 grams

Below are the a full complement of accessories in the package with Alcatel Y900.

In addition to the router, buyers will get the power supply cable, micro-USB 3.0, cable USB OTG (with connector micro-USB 2.0) and warranty card.

Appearance

The body of Alcatel Y900 router is made of soft-touch plastic in two colors: gray-white and black. Both will not collect fingerprints. In small dimensions, the gadget is a little bit heavy because of the large battery.

On the front panel, there is a LED power indicator and a large four-level indicator of network signal: depending on the power of the contour, segments are highlighted in blue. But the battery charge level can be found only in the web-based interface.

Three more LEDs are on the left side of the router. They show which network the device is connecting.

The top of the body is the power button and WPS button for fast set-up Wi-Fi. Port micro-USB 3.0 is at the lower bound of the gadget.

Under the rear lid are the removable battery slot for micro-SIM and memory cards microSD.

Interface

Get access to the Alcatel router in two ways: either by connecting the device to a Wi-Fi (the password for the initial configuration is located on the back of the back cover), or by connecting the gadget to PC USB-cable. In the second case, you must first install the driver that is in the memory of the router. By the way, the computer recognizes the device as a CD-drive.

Web-based interface of Alcatel One Touch Link is available at «http: //y900.home» and is password protected. At the entrance, the red button “off the Internet” attracts the attention. This decision was taken for good reason: to change a number of settings is possible only with the disabled connection, and it can be done at any time, without returning to the home screen. Next to the duration of the session the current data rate is displayed. If network access is disabled, the inscription changes to “Connect the Internet.”

Most actions can be operated directly from the web-based interface with SIM-card, which allows reading and sending SMS, contacts and work with USSD-command.

After log in the web interface, Alcatel One Touch Link Y900 begins in the “Settings”, and the most useful of them is that the possibility of switching to 4G, which offers a much higher rate than other standards even at a weak signal.



In the «Wi-Fi», there are all wireless network settings, you can select the SSID and disable its broadcast, set the type of encryption, and set the maximum number of clients from one to maximum 32. In the tab “Advanced Settings” to choose between the 2.4 or 5 GHz band, but the simultaneous operation in both would increase the power and cost of the router significantly.

On the “Energy Saving” in the “Device”, you can adjust the range of the Wi-Fi network. If the router is in your bag, and you want only share the network to your devices (such as a smartphone and a laptop), the setting will be enough “Small range Wi-Fi networks.” Then the gadget will last much longer time without recharging in this case.

Section “Firewall” to configure port forwarding, and the demilitarized zone (DMZ). This functionality is sure to be useful to power users in the event of a “white» IP-addresses.

DHCP-server settings are located in the “router” if automatic assignment of customers to IP-addresses is not desirable, you can turn off the server and assign them manually.

Despite a decent functionality, the Alcatel One Link Y900 router is as simple as possible for inexperienced users to log into the network, simply insert the SIM-card and enable the device, no further adjustments are required.

Despite the fact that the gadget is sold by the operator “Beeline”, and its web-interface explicitly made in the company’s “bee” style, the Link Y900 router can work with any SIM-cards of other operators. This possibility can not be overestimated, especially to those who travel frequently and avoid overpaying for roaming.

The router supports microSDHC – memory card up to 32 GB, which allows it to act as a card reader. When connected to a PC You can transfer files in both directions, but the memory card access via Wi-Fi manufacturer somehow had not foreseen.

Thanks to high-capacity battery, the One Touch Link Y900 can charge other devices, and this is useful for a complete cable USB OTG. It is unlikely that such a function should be considered among the basic, but it can be very useful in an emergency, such as when you need to make a call and your phone battery is at zero.

Another feature of the device is the support of USB 3.0. The speed of data transmission in LTE-Advanced can reach 300 Mbit/s and a maximum speed through Wi-Fi 802.11n with one antenna is 150 Mbit/s, the use of USB 3.0 for connecting the device to a PC or notebook looks quite reasonable.



Wireless interfaces

Alcatel One Touch Link Y900 supports all generations of mobile networks up to LTE-Advanced (or sometimes referred to as the standard 4G +). LTE-A network provides data transfer rates up to 300 Mbit/s, but unfortunately, it’s not yet very common.

Do not forget that the 300 Mbit/s speed of data transmission is in perfect conditions and close proximity to the base station. And if you want it in the LTE-A, you need find out whether there is coverage in the location where you want to use a router.



As for Wi-Fi, the device has the support of all modern standards 802.11a/b/g/n/ac in the frequency bands 2.4 and 5 GHz. Alcatel Router is equipped with Li-Ion battery impressive capacity 3600mAh. For eight hours of continuous operation of the device battery has run about 40%.

Conclusion

The Alcatel One Touch Link Y900 manufacturer TCL managed to find a balance that can reconcile a variety of user groups. The device does not require any special installation – Insert the SIM-card and you’re done, but amateurs with their hands “pull splitting” will be pleased with the rich possibilities of functions, in which the router bypasses most competitors.

The main feature of Alcatel Link Y900 – support for LTE-Advanced, allowing you to enjoy access to the internet at ultra-high speeds. But even if the network is not available LTE-A, the gadget will be one of the best 4G-routers with support for all Wi-Fi standards and significantly longer battery life. It’s a great mobile 4G router!



Huawei B315 4G LTE Router

Since the summer of 2015, a new LTE router Huawei B315 for speeds of up to 150 Mbit/s download is available. As the device also provides four fast Gigabit LAN ports, a wireless interface and a phone interface, it is ideally suited as a DSL replacement. The Huawei B315 router can also be used with UMTS and GSM network in addition to LTE. In the following information sheet you will find all the details for Huawei B315.



Features and Specifications of Huawei B315

Manufacturer and type designation:

Huawei B315s-22

Chipset:

HiSilicon

LTE Category:

LTE modem category 4 (3GPP Release 9)

Download rate

Up to 150 MBit/s

Uploadd rate

Up to 50 MBit/s

Supported LTE bands:

LTE800, LTE900, LTE1800, LTE2100, LTE2600MHz

Backward compatible with:

DC-HSPA+, UMTS, GSM (900 and 2100 MHz UMTS)

Support of LTE-Advanced:

no

MIMO Support:

2×2 MIMO

External antenna connector:

yes by SMA (Buy Huawei B315 Antenna)

Telephony

With integrated telephone system:

Yes, but only via 3G mobile

Connection for analog telephones:

Yes 1 x RJ-11

integrator answering machine:

no

Network | LAN & WLAN

LAN Ports:

4 x RJ45 Gigabit ports

WLAN Standards:

WLAN 802.11 a/b/g/n at 2.4 GHz

5 GHz WLAN support:

no

Encryption:

WEP, WPA, WPA2

Others

Dimensions:

186 x 139 x 46 mm

USB:

1x USB 2.0

Memory card expansion:

no

Release:

July 2015

available at:

www.4gltemall.com





LTE with up to 150 Mbit/s



The Huawei B315 Router has an integrated multimode modem for LTE, UMTS and GSM networks. In LTE network speeds of up to 150 Mbit/s downstream and 50 Mbit/s upload is supported (LTE Category 4). In the UMTS network, up to 42.2 Mbit/s in download via the data accelerator DC-HSPA+ is available. If reception is poor, user can connect external antenna to the Huawei B315 which has two SMA interfaces on the back, which are hidden under a cover.



Equipment such as computers, laptops, tablets and smartphones can be connected with the Huawei B315 either via WLAN or Ethernet LAN interfaces. The four RJ45 LAN ports operate according to the Gigabit standard, thus enabling data rates of up to 1000 Mbit/s. They are therefore also ideal for network hard drives incorporate or stream HD movies on your home network. The wireless connection is up to 300 MBit/s fast, but only supports the frequency range of 2.4 GHz and 5 GHz band.





Phone function without VoIP



Huawei B315 can connect an analog phone via the rear RJ-11 port. If the inserted SIM card phone connections, the router can therefore be used for outgoing and incoming calls. However, the router can only support telephone calls via the GSM and UMTS mobile network. The VoLTE is not yet available on huawei B315, and the voice calls over the Internet regardless of the inserted SIM card are is not supported.





Availability and price

The Huawei B315 LTE router is now available without a contract and without SIM lock in online trading, for example, on www.4gltemall.com. The device is only available without a contract, the mobile phone operators in Germany, Austria and Switzerland do not sell the Huawei B315. If you like this new router, you can refer the online store www.4gltemall.com .



1 & 1 Mobile WLAN LTE Stick- ZTE MF79

1 & 1 has a new LTE-Stick on sale, it’s based on the model ZTE MF79 and it provides wireless networks for laptops and tablets, regardless of an Internet or public WLAN. The Mobile Wireless LTE Stick ZTE MF79 can provide as a hotspot for up to ten devices.

LTE features and specifications of ZTE MF79
Manufacturer and type designation ZTE MF79
LTE Category: CAT4
Download rate up to 150 MBit/s
Upload rate up Up to 50 MBit/s
Supported LTE bands 700 MHz/1800 MHz/2600 MHz
Backward compatible with: UMTS / GSM
MIMO Support: Yes
Connector for external antenna no
Hot spot function via WLAN Yes, for up to 10 devices
Chipset not known
Others
Dimensions 101 x 30.5 x 13.5 mm
USB standard USB 2.0
Memory card expansion Yes; MicroSD up to 32 GB
Compatible Operating Systems WindXP, Vista, Win 7, Win 8, Win 10, Mac OS (from 10.4)

Technical specifications



If the 1 & 1 stick connected via USB to a PC, laptop or even a TV, it can provide these with Internet and Wi-Fi. The wireless LAN 802.11 b/g/n supports at 2.4GHz. Whether the 5-GHz band can be used, is unclear. The ZTE MF79, which replaces its predecessor MF70, could work on LTE network – providing matching mini-SIM and an LTE tariff. With LTE CAT4 technology, the theoretical download speeds of up to 150 Mbit/s are possible; in the upload it can take up to 50 Mbit/s. However, the offer of 1 & 1 are initially limited to up to 50 Mbps.





WiFi Hotspot for 10 devices

If there is no LTE network available, it goes seamlessly with 3G or 2G speed. To write and receive SMS is possible. As a mobile Wi-Fi hotspot, 1 & 1 stick can also provide up to ten devices such as smartphones, tablets, laptops or other Wi-Fi-enabled devices in parallel with wireless internet. The connection between stick and terminal is established automatically via Wi-Fi, an installation is not necessary. Of course, all of the latest encryption including WPA/WPA2 and TKIP/AES are possible in order to ensure reliable data transmission.



The 1 & 1 stick should of course make good traveling services primarily. Therefore, a USB cigarette lighter adapter is included in delivery for the drive. So the MF79 can be recharged while driving and provide for all occupants mobile internet via WLAN. The LTE-Stick can be also charged on a laptop or home PC with the included USB cable. Of course with the USB power adapter, the fast charging via outlet is possible.

Second function as a USB stick

The ZTE MF79 is about eleven centimeters long and weighs 32 grams. On the front two LEDs are installed that indicate the connection with either the WLAN or the cellular network. The 1 & 1 stick can also be easily used as a USB storage device: It has a Micro SD slot, which accommodates memory cards up to 32 gigabytes.



Availability

The ZTE MF79 Mobile WLAN stick LTE is now available on www.4gltemall.com in good price. No SIM lock, no contract required. You can use the LTE stick with any network providers in Europe and Asia. And there is similar models such as Huawei E8278 and Alcatel W800, if you like other brand, you can try them.







ZTE MF283 4G LTE Router Review

The Chinese manufacturer ZTE has launched with the a new LTE router MF283 on the market, which supports LTE Category 4 and allows speeds of up to 150 MBit/s in the downlink and up to 50 Mbit/s in the uplink. Terminals could be connected with ZTE MF283 either through wired LAN interfaces or wirelessly via WLAN. The router not only provides a fast Internet connection, you can also make calls over the device thanks to Voice over IP, provided that the provider allows. In Austria, the router is marketed as “Webgate 3“.

Features and Specifications of ZTE MF283

Manufacturer and Model

ZTE MF283

Download rate

up to 150 MBit/s

Upload rate

up to 50 MBit/s

Supported LTE bands:

800 MHz/1800 MHz/2600 MHz

LTE-Advanced Support

no

Backward compatible with:

UMTS; GSM; HSPA+

MIMO Support:

MIMO 2×2

Connector for external antenna

yes, 2 SMA sockets(Buy ZTE MF283 Antenna)

Category:

LTE category 4 (CAT4)

Telephone

With integrated PABX

Yes

VoLTE Support (Voice over LTE)

Yes

Operating Internet (VOIP)

Yes

Connection for analog phones

Yes, 2xRJ11

Connection for ISDN

no

DECT

no

integrator with Voice Mail

no

HD voice possible

no

Network | LAN & WLAN

LAN Ports

4 LAN (RJ45), 100 Mbit/s

Wi-Fi standards

WLAN 802.11b/g/n for up to 32 devices

5 GHz Wi-Fi support

no

Coding

WEP, WPA, WPA2

WLAN guest access installable

no

Others

USB

yes, 1 x USB 2.0

Dimensions / Weight

195 mm * 150 mm * 55 mm

IPv6 Support

Yes

NAS capability

no

Power consumption ca.

unknown

used as a Media Server

no

Available at

www.4gltemall.com



Fast Internet over LTE



The ZTE MF283 dominated all three mobile technologies currently used in Germany: GSM, UMTS and LTE. In the UMTS network the data accelerator DC-HSPA+ is supported, so depending on your plan and network utilization up to 42.2 Mbit/s in the downlink and 5.76 Mbit/s can be achieved in the uplink. It is fast when LTE can be used. Based on LTE Category 4, speeds of up to 150 MBit/s in the downlink and 50 Mbit/s in the uplink are possible.







The Internet connection is optionally provided via one of the four LAN ports on the back of the ZTE MF283 or wirelessly via WLAN. However, the LAN ports operate with a maximum of 100 Mbit/s, so that the full LTE speed can not be exploited. The Wi-Fi 802.11b/g/n is in the 2.4 GHz frequency band, on other hand, speeds of up to 300 megabits per second are possible, according to ZTE, depending on how far you walk to the terminal from the router.

Integrated Phone function



On the back of the ZTE MF283, there are two RJ-11 ports for analog phones, and a DECT interface for connecting wireless phones. The telephone is not made directly on the SIM card, but via VoIP directly via the Internet connection. A corresponding VoIP tariff is of course a prerequisite for using the telephone function.





Other interfaces

In addition to the four LAN ports and two RJ-11 phone connectors, a USB port can be found on the back of the ZTE MF283. Normally, the USB port is storage devices or printers. On the back you will find two connections for an external antenna. This feature works in areas with weak signals as connection quality and speed can be optimized.



Availability

The ZTE MF283 is in white color with the Austrian network operator “3” in the form of “3Webgate 3”.  If you prefer the unlocked ZTE MF283, you can check the site www.4gltemall.com for more details.



1 & 1 LTE Mobile Stick – ZTE MF823

Since summer of 2014, 1&1 also has its tariffs for mobile surfing via LTE. The basis for this is a more compatible LTE surf stick. The model number is ZTE MF823. This can be ordered as an option to new contracts. We show the features and specifications about 1 & 1 LTE Stick.

LTE Feature and Specifications of the 1 & 1 LTE sticks

Manufacturer and model

ZTE MF823

Download rate

Up to 100 MBit/s

Upload rate

Up to 50 MBit/s

Compatible LTE Bands

LTE 800, 900, 1800 and 2600 MHz

Backward compatible with:

DC-HSPA+, UMTS, EDGE, GPRS

MIMO Support:

MIMO 2×2

Connector for external antenna

Yes; 2 aerial socket type TS-9 available(Buy ZTE MF823 Antenna)

LTE Category:

LTE modem category 3 (3GPP Release 8)

Chipset

Qualcomm

Others

Dimensions

90 mm x 28.4 mm x 13 mm

USB standard

USB 2.0

Memory card expansion

Yes; MicroSD up to 32 GB

Compatible Operating Systems

Windows XP, Windows Vista, Windows 7, Mac OS (from 10.4)

Availability

www.4gltemall.com





While Telekom and Vodafone mostly rely on products from Huawei, ZTE cooperates with 1 & 1. Behind the 1 & 1 LTE stick, it hides the model number ZTE MF823. In addition, 1 & 1 offers a mobile 4G Router (MF910) at flat rates in connection with his laptop. The LTE Stick is with a non-branded, white version with ZTE logo.



Technical characteristics

1 & 1 LTE-Stick is a solid, typical middle class model. It supports LTE category 3 hardware, so that the downstream hypothetically to 100 Mbit/s could be achieved. For Notebook Flats that was good enough, as the rates offer only up to 50 MBit anyway. The device can communicate at 800, 900, 1800 and 2600 MHz by 4G. Since 1 & 1 only runs on 1.8 GHz, the MF823 stick could also work with other network partners such as Vodafone, O2, E-Plus etc.. But you must unlocked the 1&1 LTE stick. If there is no LTE reception locally, the drive switches to 3G or 2G standards, so that nevertheless could be surfed. If the signal is not good, over 2 sockets (TS-9) also can connect an antenna for improved reception.



Operation and Installation

The installation is quite simple. Like many modern sticks, the 1 & 1 LTE stick also comes now without installing an extra software. The operation and configuration takes place, easily accessible via the browser. After first plugging it starts once a setup. This installs the necessary drivers, as well as an icon on the desktop “4G Hostless Modem” applies. After a short time, it further launches a browser window with the ZTE logo. Until this process is completed, it passed no more than 30 seconds.







Conclusion

A for the 1 & 1 LTE offers quite suitable and uncomplicated stick for a small price. Simply plug in and start surfing – so it should be a good partner to surf internet. But if you prefer the original factory model, you could check the ZTE MF823 directly from www.4gltemall.com .





Speedbox mini II Router – Huawei E5786

The Speedbox LTE mini II is a new portable router for Germany Telekom, which has great improvement from its predecessor especially at speed. Because the new router is based on LTE CAT6. This compact device can be used both for home use, as well as for the road. Here are the technical data at a glance.





Features and Specifications of the Speedbox Mini II

Manufacturer and model

Huawei E5786 Mobile Wi-Fi
Download rate Up to 300 MBit/s
Upload rate Up to 50 MBit/s
Compatible LTE Bands 800/850/900/1800/2100/2600MHz
backward compatible with LTE CAT 3 & 4, DC-HSPA+, HSPA+, HSDPA, UMTS, EDGE, GPRS, GSM
Support of LTE-Advanced Yes
MIMO Support: MIMO 2×2
Connector for external antenna Yes; 2 aerial socket type TS-9 available(Buy Speedbox Mini II Antenna)
LTE Category LTE modem of Category 6 (CAT6)
Chipset Hisilicon | HPM Coretx A9 processor
Wi-Fi standards 802.11 a/b/g/n/ac

Wireless Internet Hotspot

yes – for up to 10 devices
Others
battery 3000 mAh (up to 10h surfing time)
Dimensions (WxHxD) 106 x 66 x 15.9 mm at 145 grams
USB standard USB 2.0
Memory card expansion Yes; MicroSD up to 32 GB

Compatible Operating Systems

Windows XP SP3, Windows Vista, Windows 7 & 8, Mac OS (from 10.7)
available at www.4gltemall.com



In January 2013, Speedbox LTE mini came out. Again, a model was used as the previous model, which is based on a device from Huawei. The model number is Huawei E5786.

Highlights of Speedbox LTE mini II

Instead of LTE category 4 with the frequency bands 800/900/1800/2100/2600 MHz, the Speedbox LTE mini II is now with Category 6 and supports more bands with additional 4G at 850 MHz. Thanks to LTE CAT6, a maximum download rate of up to 300 Mbit/s is possible, which is twice the first Speedbox LTE mini. In addition to the normal Speedbox II, this is the first LTE-Advanced router available in Germany. The particularly fast standard 802.11ac allows here a data transfer of up to 433 Mbit/s, while the module sends on 2.4 GHz and 5.0 GHz.



The capacity of the battery was 3,000 mAh available. The dimensions remained almost the same as E5786, only the weight more slightly to 5 grams. The Speedbox Mini LTE is powered by a new chipset from Huawei HiSilicon, which comes along in 28-nanometer architecture Cortex-A9 architecture and allows the use of LTE CAT6. Furthermore, if the high-speed internet is not available,  you can also rely on HSPA (+) with up to 43.2 Mbit/s, and EDGE and GPRS are also supported.





Wireless Internet Hotspot



The small dimensions make the Mini-Router an ideal travel partner. At the same time, the device has a hotspot feature that allows up to 10 other terminals to access the Internet. It’s perfect to use it in apartments without power, or in the car etc.







Availability



The Speedbox LTE mini II can be ordered at Germany Telekom since mid-September 2014. At the Telekom, it will not only provides the network operator logo on the surface, a software-branding is also available. Thus for example, the wireless repeater function of the E5786 has been disabled.  If you know the difference between the Speedbox LTE Mini II with E5786, you many prefer the unbranded Huawei E5786 with full functions activated. Without any SIM lock, you can take the pocket WiFi anywhere!



TP-Link M7350 4G LTE Mobile Hotspot

The Chinese network specialist TP-Link presented a new model M7350 as new mobile hotspot with wireless support for up to 15 devices in the program. The router adopts LTE Cat4 and shows all the necessary information on its display. The TP-link M7350 is portable enough to take on the road to provide fast Internet reception.

Features and Specifications of TP-Link M7350

Manufacturer and Model:

TP-Link M7350

Chipset:

Qualcomm MDM9225

LTE Category:

CAT4

Download rate:

Up to 150 Mbit/s

Upload rate:

Up to 50 Mbit/s

Supported LTE bands:

800 MHz / 1800 MHz / 2600 MHz

Backward compatible with:

DC-HSPA+ / UMTS / GSM

Support of LTE-Advanced:

no

MIMO Support:

no

External antenna connector:

no

Telephone

With integrated telephone system:

no

Connector for ISDN telephones:

no

Connection for analog telephones:

no

DECT:

no

integrator answering machine:

no

Network | LAN & WLAN

LAN Ports:

no

WLAN Standards:

Wi-Fi 802.11a/b/g/n

5 GHz WLAN support:

Yes

Encryption:

WPA-PSK / WPA2-PSK

Wireless Internet Hotspot function:

Yes, for up to 15 devices

Others

Battery Capacity:

2,550 mAh, exchangeable

Dimensions:

106 x 66 x 16 mm

USB:

MicroUSB

Memory card expansion:

Yes, Micro SD up to 32GB

Release:

September 2014

available at:

www.4gltemall.com



Technical Features

With the TP-Link M7350, the user can dial in LTE networks of category 4 and thus achieves download speeds of up to 150 Mbit/s and 50 Mbit/s upstream. What’s more, the router is of course backwards compatible with 2G and 3G networks with a maximum of 42.2mbit/s with DC-HSPA+ and then HSDPA 7.2 Mbit/s. This also fits any SIM card because it contains even a card adapter for Micro-SIM and one for nano-SIM cards with the delivery of the router, in addition to micro-USB cable and power sup ply,.

TP-link M7350 Battery

Up to 15 devices can be connected

It’s a pity  that the TP-link M7350 has not the connection ports for external antennas to improve reception quality. In WLAN, the M7350 supports the 802.11 a/b/g/n on 5 GHz and 2.4GHz, and the faster WLAN ac with up to 300 Mbit/s download speed. Up to 15 devices could be connected to surf via the mobile hotspot on the Internet.

Informative display

Around just 11 x 7 centimeters of the mobile hotspot, it is pleasantly easy to handle and the screen shows sufficient information on its 1.4 inch TFT LCD display about the data volume, the Wi-Fi state, the number of connected devices, the network type (4G/3G/2G), the signal strength, the Internet connection status, incoming messages as well as the battery state of charge.

Access via the device or PC

Using the menu button of the TP-Link M7350, the user can change the network or also switched roaming rapidly and off on the road and have a look at the wireless password. Advanced access to all functions of the router could be done via the web interface of the device from the PC. An app to control does not exist unfortunately. Supported operating systems include Windows from XP, Mac OS, Android and iOS.

Practical SD card slot

The equipment of the M7350 also has a Micro-SD card reader, the card takes up to 32 GB capacity. Access to the card is done via a corresponding Explorer via iOS or Android, so you can share photos or music from the SD card on all connected devices.

TP-link M7350

Replaceable battery

The TP-Link M7350 battery provides decent 2550 mAh and is fortunately removable. According to the manufacturer, the battery will last through up to 10 hours surfing the LTE network. Charging the battery can be done via the included Micro-USB cable either on the PC or an adapter on the socket.



Availability

The mobile router TP-Link M7350 is available in black in various online stores such as www.4gltemall.com for free trade.



Conclusion

The new router from TP-Link M7350 scores with LTE Cat4, replaceable battery and SD card slot. If you need a pocket router with a connection for an external antenna as well as the operation via a smartphone app, TP-Link M7350 may not be a good option. You could choose other brand such as Huawei E5786 or Netear 782s. But except that, the TP-link is a good 4G router.



Netgear AirCard 790S 4G LTE Cat6 Mobile Hotspot

Netgear has introduced its newest member of the AirCard 790s to the router family. The Netgear AirCard 790S is the first mobile hotspot in Aircard 7X0s who supports the LTE Cat6 with up to 300 Mbit/s in the download. Actually, Netgear 790S is not the first LTE cat6 mobile hotspot because Huawei had presented the Huawei E5786, which is the first one.

Telstra WiFi 4G Advanced II screen



Technical Features



The AirCard 790s is equipped with a 2.4-inch, color LCD touch screen. The screen displays the network icon, signal strength, the network name, the wireless status, battery status or data usage. And the touch icons takes you to the Settings and other menu items. The router can also be configured on the PC or via an app on your smartphone or tablet and use. The AirCard app is available for iOS, Android and Kindle. Here you can retrieve all possible information.

Telstra WiFi 4G Advanced II antenna ports

LTE-Advanced with 300 Mbit/s



The AirCard 790S Netgear supports LTE Category 6, backward with both 2G and 3G networks, including DC-HSPA+. If you live in an area covered with LTE-A field and has a micro-SIM card with an appropriate data plan, using Carrier Aggregation, two 20 MHz bands are combined into a 40-MHz band in downlink, so as to allow download speeds of up to 300 Mbit/s. Carrier aggregation of 2 x LTE2600 is supported as well as the pooling of 2.600 and 1.800 MHz.

Telstra WiFi 4G Advanced II back logo

Additionally, the AirCard 790S also widespread in the US 700 MHz band used for LTE-A: The router is thus prepared. In upload, up to 50 Mbit/s are possible with the hotspot. If the wireless coverage at home or on the go too weak, user can connect two external antennas for 3G/4G to the router.





Features and characteristics of the AirCard 790S
Manufacturer and Model Number Netgear AirCard 790S
Chipset Qualcomm MDM9230
LTE Category CAT6
Download rate 300 Mbps
Upload rate 50 Mbps
Supported LTE Bands: 700 MHz / 1800 MHz / 2600 MHz
Backwards compatible with LTE CAT4 / DC-HSPA + / UMTS / GSM
Support from LTE-Advanced Yes
MIMO Support: 2×2
Connection for external antenna: Dual TS-9 for 4G / 3G
Telephone
With integrated telephone system No
Connection for ISDN phones: No
Connection for analogue phones: No
DECT: No
integrator answering machine: No
Network | LAN & WLAN
LAN ports: No
WLAN standards: WLAN 802.11 b/g/n/ac
5 GHz WLAN support: Yes
encryption: WPS, WEP, WPA, WPA2
WLAN hotspot function: yes, for up to 15 devices
Others
Battery pack: 2,930 mAh, changeable
Dimension: 110 x 68 x 15 mm
USB: Micro-USB 3.0
Memory card expansion: No
release: Nov-15
Price: about 229.00USD
available at: www.4gltemall.com
Documents download
Datasheet » Netgear AC790S Datasheet
Read review » Netgear Aircard 790s Review
Manual as PDF » Netgear Aircard 790s manual(PDF)

Supply 15 devices with fast Wi-Fi

The Netgear 790S supports the standard Wi-Fi ac on 2.4 and 5 GHz. As a hotspot, the router can support up to 15 devices with wireless Internet while other competing models supports maximum devices to 10 units. The network can be encrypted with WPA2, which is set by WPS. If you connect the router via USB 3.0 to a computer, it can be charged at the same time and provide the PC with high speed internet.

Telstra WiFi 4G Advanced II Aircard 790s battery

Strong and Replaceable Battery

Netgear has his latest AirCard model a strong power source: The battery has capacity of 2,930 mAh, which should be enough for up to 10 hours in operation and 350 hours in standby according to the manufacturer. The router can be charged via the included Micro-USB cable, the 790S also can be used as a charging station for a smartphone itself. The battery is fortunately interchangeable; Netgear offers optional at an even stronger battery with up to 16 hours of run time.



Availability

The AirCard 790S Netgear is available on www.4gltemall.com . And it’s the unlocked version, which means it can work well in North American, Asia and European countries.



Conclusion

The AirCard 790S Mobile Hotspot Netgear has a high-speed router at the start, which is not only fast, but also future-proof. LTE Cat6 and WLAN ac plus support for the 700 MHz band and supply of 15 devices with Wi-Fi, users do not have to provide a lot of competitors. What’s more, the 790S is quite handy and provides an informative color touch display. It’s a real practical and cool 4G pocket router!
