Category: New Products

HUAWEI E372 HSPA+ 42Mbps USB Stick Review

This HUAWEI E372 modem is the first device which works in Dual Carrier HSPA+. What can users benefit from this USB Stick and what are the features of the E372? Today, we will have a review of its details.





Huawei is a well known and respected manufacturer for wireless 3G or 4G modems. This time we tested the instruments in the HSPA+ Dual Carrier. This technological innovation allows you to download data from the Internet at incredible 42 Mbit/s under certain mobile conditions. This rate is several times higher than most cable Internet connections in Europe and Asia!





The HUAWEI modem E372 looks simple – like a typical device of this kind, wrapped up in a pretty case. Besides, the obvious SIM card slot is hidden at the bottom of the case. On the other side, you will find the plug socket for external antenna. The connector is TS-9.  Another feature is a microSD card slot. When placed in the card, the modem can be used as a stick.





HUAWEI E372 could work with qual-band UMTS 850/900/1900/2100MHz, which almost covers all the WCDMA networks all over the world. So HUAWEI E372 is one of the best 3G modem to roam around the world. This powerful function make E372 one of the most popular 3G dongle now only at the operators, but also the end users. The E372 stick can quickly be configured to work in almost all operating systems. This applies to both Windows version XP SP2, Vista and the latest Windows 7 and Linux. For T-mobile, it’s named Web Stick 42, which means it could support HSPA+ 42Mbps data rates.







The installation process is extremely simple. Just put the modem into the USB port and wait for the auto installer application configure the connection. All drivers and instructions are loaded into the device into your computer, so users do not need to insert the CD-ROM drive. The entire installation takes a while and requires just a few click. After a while, we can enjoy the benefits of the Internet.



The setup program will bring up information on the signal level and standard network connection. From the application, we can also monitor the data transfer and send SMS messages.





Huawei E372 is a hell of a high-speed modem, so that we will be able to use the internet at speeds in many places exceeding the possibility of a cable network. It’s hard to believe, but the development of technology, mobile internet connection already allows it. Weighing 33 grams, HUAWEI E372 USB modem did not cause us any problems during the test, and the installation takes very short time. With the ability to connect an external antenna and use it as a portable storage, HUAWEI E372 is really a good partner for businessmen and tourist.



Here now HUAWEI has a new Hilink USB Stick which could also support DC-HSPA+ 42Mbps, the model number is HUAWEI E3251. It can auto connects in 5 seconds after plug in, no installation is needed. If you are interested in this new model, welcome to check on www.4gltemall.com .

ZTE MF195 3G HSDPA Mobile Internet Stick Review

Choosing the right USB modem for mobile internet is not easy. Therefore, we have to test another model, this time it’s from ZTE, and see if you are interested in this one.



One might think that it’s nothing. We need a little gadget that you insert into the USB port and configured to give us access to the mobile internet. It is worth to pay attention, both on the modem parameters, as well as any additional features that can benefit the users.





ZTE MF195 USB modem is a relatively new device offered by T-Mobile, which is consistent with the standard HSPA+ technology. According to official specification, we can achieve download speeds at up to 21 Mbps. The HSUPA upload speed could reach up to 5.76 Mbps. But under real environment, the speed may be only half or more.





New software for the modem ZTE MF195



There is new software that improves the performance of the MF195 modem. You can download them here – just that you click the “Downloads”.



The device ZTE MF195 itself has a removable top flap, under which there are slots for SIM card and a microSD memory card (supports up to 32 GB capacity). You have to admit, it’s a fantastic deal. If you just do not use a modem to connect to the Internet, we can always treat it as a normal flash drive, storing files. Of course, the same USB connector is safely protected from dust and debris particles from the environment. It is a pity that the cap is not somehow attached and can easily be lost. A great advantage of ZTE MF195 USB is built-in socket used to connect an external antenna. It certainly can be useful in areas with slightly weaker coverage. Users just need set aside a small cap and connect an external antenna (sold separately).





Modem Setup is basically maintenance-free. When plugged in the USB port, it will automatically install the drivers and software for Internet Manager. When it starts only give the code to the SIM card and wait for the Connect button, and then it will become active. And this happens almost instantly and you can see that both the hardware and software to work fine. The modem’s LED indicates the connection status.





User check speed Internet connection using specialized tools – SpeedTest. At the border of Downtown and Will in Warsaw, where we have tested the modem, we were able to achieve data transfer rates of 13 to 14 Mbps, and upstream from the network was about 3 to 4 Mbps. This is a very good result. All services and web pages load quickly, even without an external antenna, the modem does not lose coverage. ZTE MF195 USB therefore works very stable. During the next day’s test, changed the location in the city, and each time the modem connect to the network instantly.









In conclusion, the ZTE MF195 USB modem is definitely recommendable. It takes very little space and provides a stable access to the mobile Internet and a decent download speed and upload the data .Not to forget about the extra features, the built-in socket for connecting an external antenna and a slot for memory cards microSD.





Here now, there are many upgraded USB stick, such as ZTE MF668 and ZTE MF821 available with much high speed and stable connection. If you want to experience better, you can check them on 4gltemall.com .



Huawei E353 HSPA+ 21Mbps USB Stick Review

This modem HUAWEI E353 provides lightning-fast network connectivity and ultra-fast. Today, we will introduce the HUAWEI E353 3G high speed internet stick.



HUAWEI E353 is not the latest model from Huawei, but it must be one of the most popular USB Modem and it does not cost much and has an impressive performance. The device looks like most 3G modems, connected via USB – inconspicuous. The quality of plastics used is satisfactory, and easy slide of the back cover makes it very user-friendly. The E353 also has CRC9 aerial socket from which you need to use if you want to work at high speed in difficult conditions. The design is minimalist, and we can choose the following colors available: white, black, black and white, and pink. Modem weighs only 26 g.





Huawei E353 connects to the internet in just 15 seconds when connected to the computer. It’s a really good result, which will save us unnecessary expectations. The speed at which your modem connects to the network is up to 21 Mbps (HSPA+) – more enough for the majority of Internet users. The uploading takes place at a maximum speed of 5.76 Mbps. Both parameters are significantly better than the performance of broadband connections in Europe and Aisa.

Modem connection service can be instantly set up to work in almost all operating systems. This includes Windows versions XP SP2, Vista and the latest Windows 7 and Linux. The Mac OS X is also supported.



The installation process is very easy. After placing the modem into the USB port, just wait until the auto installer application used to configure the connection. All drivers and instructions are loaded into the Huawei E353 into your computer so do not need to insert any disc. The entire installation process takes a while and requires just a few clicks and entering a PIN. Then we can freely enjoy the benefits of the Internet.





The setup program will bring up information on the signal level and standard network connection. We can also monitor the data transfer and send SMS messages. During the tests, the modem e353 has worked stable and did not notice problems such as breaking up or losing coverage.







Huawei E353 is the perfect choice for reasonable money; it’s a well-built mobile internet stick. HUAWEI E353 will provide us with high-speed internet access in all conditions. Rapid installation and trouble-free service will certainly appeal to all users. The external antenna connector is a nice add-on that can be useful in difficult conditions.



Here now there is 42Mbps USB Stick upgraded from E353, they are HUAWEI E3251 and E372. If you want higher speed, you may check Huawei E392 or E398 4G LTE Sticks.



If you want to buy unlocked Huawei E353 USB stick, click here: https://www.4gltemall.com/huawei-e353-3g-umts-hspa-hsdpa-21mbps-usb-surf-stick.html

HUAWEI E3131 3G 21Mbps Hilink USB Stick Review

To choose the right USB modem, it depends not only on the speed and efficiency of the mobile internet. As a result, it will also depend on the experience of using a computer. Most of us use it almost exclusively online. But when you use a USB Dongle, it may be already outline.



Huawei E3131 USB modem looks simple, just like the other common type of USB dongles. The black case is made of really good quality plastic. This white logo of T-mobile breaks the ubiquitous black and makes it look much interesting than most competitors. Under the removable lid there are two slots, the larger one, placed on the top is the place where you put the SIM card. The smaller one, on the side is the pace to mount its microSD memory cards up to 32 GB and use the modem like an ordinary USB flash drive, even when connected to the Internet.







On the body, we can see small plug socket for external antenna is hidden under a small cap. It is worth to use it if you intend to use mobile internet in bad network conditions, for example in buildings constructed so that effectively suppress cellular network coverage. In our tests, however, we did not take advantage of this opportunity – because Huawei is working very stable and does not lose coverage so easily. Enclosure E3131 hides another, a small but very useful curiosity – a solid metal handle leash. The string can also drag the USB connector cap to prevent it from getting lost.



The installation consists of connecting it to the USB port. The operating system automatically recognizes the device and installs the appropriate drivers.



Installation process as simple as connecting it to the USB port- The operating system automatically recognizes the device E3131 and installs the appropriate drivers. The driver is stored in the modem, so we do not need to use additional software that comes on additional media. With Windows 7, you only need to manually run the installer for the Internet Manager. However, it is very easy and it boils down to virtually one click. If you are using the latest Windows 8, you do not have to do even that – everything will be completely automatic.





In addition to the connection to the internet, leading Internet Manager Panel also gives you access to many useful options. With it, you can send and receive text messages, check history of operations, the statistics of downloaded and uploaded data, and even use the subscriber’s personal account at T-Mobile. Huawei E3131 is compatible with HSPA+, which means that it is able to download data at speeds up to 21 Mbit/s. Posting is done in standard HSUPA, there is a maximum transfer rate of 5.76 Mbit/s. Such parameters freely enough to free and comfortable surfing the Internet resources. The practical results of our tests present themselves as well. Transfer speed in the test fluctuated around 14 Mbit/s for download.
Huawei E3131 modem is that you can recommend with a clear conscience, it is a small, portable and offers high-speed mobile Internet. His decisive advantages are also practical solutions, such as space for extra memory and a slot for an external antenna. And here now, there is HUAWEI E372 HSPA+ 42Mbps stick, if you want higher speed, you may need check HUAWEI E372 on 4gltemall.com . You will find something more amazing.



Unlocked Telekom Speedport II LTE Router

Since November 2012, the Germany Telekom finally has a successor to the first generation LTE router “Speedport “. Simply, the name of the new 4G router is “Speedport LTE II”. What are the advantages and what are the differences to “Speedbox”? Answers to these questions can be found in the following article, including a detailed summary of all key data for Speedport II LTE Router.











Features and characteristics of the LTE Speedport II (Telekom)
Manufacturer Model Huawei B593u-12
Download Speed up to 100 Mbit/s
Upload Speed Up to 50 Mbit/s
Supported LTE bands: LTE Band 3/7/20 (800/1800/2600MHz)
Backward compatible with: HSPA/HSPA+/UMTS (900/2100 MHz)
MIMO Support: MIMO 2×2
Connector for external antenna Yes, 2 SMA female
Category: LTE Category 3 (3GPP Release 8) Router
Telephone
With integrated telephone system no
Port for ISDN phones no
DECT no
Networking | LAN & WLAN
LAN ports 4 LAN ports (RJ45) 100 Mbps
WLAN standards Wi-Fi 802.11b/g for up to 32 users
5GHz Wi-Fi support no
Coding WEP, WPA, WPA2
USB Yes, USB 2.0
Other
Dimensions | Weight 177 mm x 193 mm x 34 mm | approx 500 grams
Color WHITE
Information material
Technical Data Sheet » Datasheet PDF
available since …  May 2012



The Speedport II with the new “Call & Surf via Funk” tariffs was launched in early December 2012 by Telekom. The router in LTE category 3 mode provides up to 100 Mbps download speed and capacity of 50 Mbps in upload. In addition, the Speedport II LTE is backward with 3G network, ie UMTS and HSPA (including DC-HSPA+). Earlier, the Telekom supplied from two different hardware versions, depending on what had just technically available at the customer network. A further improvement to the old port speed is the WLAN module. The new Speedport II now supports the latest “N” standard. Thus, home networks can reach via radio with up to 300 Mbit/s speed. There are also improvements in range and Wi-Fi reception. This is according to the manual, in confined spaces, up to 30 meters or outside up to 300 meters. There are 4 RJ45 ports with up to 100 Mbps. Under the white label, it indicates the manufacturer model is Huawei router with the ID “B593u-12“.







Fit for LTE Network in Europe





The previous Speedport LTE dominated only in the band of 800 MHz; the second version is now much more flexible. Besides the already mentioned backward compatibility, LTE band 7/20 (1800 and 2600MHz) is supported. Therefore, the Telekom in some regions also provide up to 100 Mbps data rate by Call & Surf via Funk (L) for the first time.







Unlike the SPEEDBOX





Both variants for Telekom 4G Router are confusingly similar, not only on the name. Technically, there is also almost identical design. But: When Speedport II is GSM (2G) not connected, so that the Call & Surf tariffs only run via 3G or 4G.  The Speedport LTE II is in white, while the Speedbox is packed in a black case.







Prices and Rates



The router can be purchased in the 4G shop (www.4gltemall.com) for around 399USD. And it’s SIM unlocked, if you want to change to Vodafone 4G network, you will not need to change another router.

Telekom Speedbox LTE Router – HUAWEI B593u-12

At Germany Telekom, there will soon be a successor to the “LTE Speedport “. As a new and upgraded 4G LTE router, the Huawei B593 is now presented by Telekom to public. Compared to its predecessor B390S-2, there are many improvements that are summarized below for you. In addition, you can have a general overview about the specification and features of the HUAWEI B593 LTE CPE.





Features and characteristics of the LTE SpeedBox (Telecom)
Manufacturer Model Huawei B593u-12
Download Speed up to 100 Mbit/s
Upload Speed Up to 50 Mbit/s
Supported LTE bands: LTE Band 3/7/20 (800/1800/2600MHz)
Backward compatible with: HSPA/HSPA+/UMTS (900/2100 MHz), GSM/EDGE/GPRS
MIMO Support: MIMO 2×2
Connector for external antenna Yes, 2 SMA female
Category: LTE Category 3 (3GPP Release 8) Router
Telephone
With integrated telephone system no
Port for ISDN phones no
DECT no
Networking | LAN & WLAN
LAN ports 4 LAN ports (RJ45) 100 Mbps
WLAN standards Wi-Fi 802.11b/g for up to 32 users
5GHz Wi-Fi support no
Coding WEP, WPA, WPA2
USB Yes, USB 2.0
Other
Dimensions / weight 195 (W) x 169 (H) x 64 (D) mm, at 444 grams
Color black
Information material
Technical Data Sheet » Datasheet PDF
available since …  May 2012



Huawei B593 = Telekom Speedbox LTE



As usual, the routers for Telekom and Vodafone are in difference label. To identify the devices, the appearance of the router is usually slightly modified (eg, color or some ports) and the logo of the mobile provider is customized for respect providers. The Speedbox LTE is in black color like Speedport LTE, while Vodafone B2000 is in white. But actually, they are the same model from HUAWEI B593, more accurately, the model number is B593u-12 LTE CPE.  From the label on the back of the router, we can see the details.





Improvements



The previous model Speedport LTE still belongs to the first Generation of LTE routers which were available in late 2010. Unfortunately, accordingly to the feedback from users, the Speedport LTE is not successful 4G equipment. LTE terminals were still scarce; therefore it had to be functional. The new version Speedbox LTE finally brings long overdue with new features and improvements.



First, the Speedbox is also backward compatible with 3G and 2G networks. This is important in case LTE is not available around. This features help Speedbox automatically revert to the next fastest standard. Previously, customers had to unfortunately live with a total failure, because the fall-back function was not anticipated at the Speedport. In addition, the router B593u-12 now dominates the LTE frequency bands at 1800 MHz and 2600 MHz. The predecessor was only designed for LTE800, ie designed for rural areas. The maximum data rate of HUAWEI B593u-12 is doubled to 100 Mbit/s downstream and 50 Mbit/s for upload. Beyond is a new USB port and connection for phones. Both analog telephone and VOIP should be possible.







Since, as already mentioned, the old Speedport is only capable of a wireless standard that Telekom provides far from two different modes. When choosing between the “Speedport LTE” and “Speedport HSPA”, the router Speedbox will choose depending on which standard is more available to the customer. This features is smart for the users who are not familiar with 4G Routers.





Availability

The Speedbox is available in the Telekom retail stores and online store www.4gltemall.com without LTE contracts. Many users prefer unlocked Speedbox, or more honestly, they would choose the factory model HUAWEI B593u-12 because they are just logo or appearance difference, functions are all the same and original factory model is SIM free for any operators.



Vodafone B1000 4G LTE Router

Vodafone B1000 is a new 4G LTE router for Vodafone. Behind the router, there is a stick indicating the model number of “B390s-2” and the manufacturer company Huawei. The noble, handsome white case houses an LTE modem router with WLAN. Following you will find all the important details including specifications, characteristics and overview about Vodafone B1000 4G Router.





Features and characteristics of the Vodafone B1000
Manufacturer and type designation Huawei B390s-2
Download speed Up to 50 Mbit/s
Upload speed up to 10 MBit/s
Supported LTE bands: LTE800 (band 20)
MIMO Support: MIMO 2×2
Connector for external antenna Yes, 2 SMA female
Category: LTE Category 3 (3GPP Release 8) Router
Telephone
With integrated telephone system no
Port for ISDN phones –
Connection for analog phones –
DECT –
integrator answering machine –
Networking | LAN & WLAN
LAN ports 4 LAN ports (RJ45)
WLAN standards Wi-Fi 802.11b/g for up to 32 users
5 GHz Wi-Fi support no
Coding WEP, WPA, WPA2
USB no
the provider side » Vodafone



Technically speaking, the Huawei B390s-2 is in the B1000 series. In the industry it is common to “brand” hardware from original manufacturers but with their own logo on the appearance. Also the appearance may vary slightly from the “original”. The integrated 4G-LTE modem B1000 is only compatible with the LTE band around 800 MHz. More specifically, it can on the band of 832 MHz – 862 MHz send (upload) and in the band of 791 MHz – 821 MHz receive (download).The supported bandwidth is 10 MHz. So the router is only unique for rural use up to 50 Mbit/s and is not suited for urban use. The chipset is “HiSilicon” (Hi6910), which is HUAWEI own chipset.





Telephone:

Unfortunately, the router does not have a PBX. In the LTE tariffs from Vodafone, there is no telephone available, which is of course no problem. However, the provider also offers complete packages with phone line and optionally with fixed flat rate. Customers who order the version with telephone, will note get the B1000. Alternatively, a pure LTE router together with a conventional DSL router is supplied, which is named Vodafone B2000. The Vodafone B2000 is upgraded from B1000, which is not only better in network coverage, but also the functions and performance.



LAN & wireless network properties:

The B1000 provides 4 LAN ports and of course Wi-Fi functionality for setting up a home network. The wireless network provided can be operated with standard 802.11b and 802.11g. With up to 54 Mbps integrated into the network, it can therefore support a maximum of 32 devices wirelessly (eg, laptop, internet radio). The latest “N” standard is not supported yet, which is a shame. Neither dominates the B1000 the spark in WLAN operation at 5 GHz. The LTE B2000 Router provides significantly more. And WEP, WPA and WPA2 encryption is possible options.







Extras:

The Vodafone B1000 is curiously almost twice as heavy as the technically virtually identical Telekom Speedport LTE. The weight is 900 grams, if user worry about the place to lay this device, here are the exact dimensions: 177 x 193 x 34 mm (width x height x depth).



China’s First 4G TD-LTE Handset — ZTE Grand Memo LTE U9815

ZTE’s Grand Memo LTE is poised to become the first 4G device available for sale in China, after it became the first to be awarded a TD-LTE handset permit by the Ministry of Industry and Information Technology.

The Ministry of Industry and Information Technology issued the first batch of license for 4G mobile network. Samsung, Sony, HUAWEI and ZTE got their first 4G TD-LTE network license and the four TD-LTE handsets are Samsung GT-N7108D, Sony M35T, Huawei D2-6070 and ZTE U9815.



As the first LTE Handset available for China 4G network, it has single-SIM, dual stand by voice solution used by ZTE Grand Memo LTE (Model No: U9815), a quad-band device compatible with the TD-LTE/ FDD/TDS/ GSM bands, which means it is capable of supporting simultaneous high-speed data transmission and high-quality voice calls.



ZTE Grand Memo LTE is the 4G version of ZTE’s flagship Grand Memo device, offering superior specifications including a 5.7-inch high-definition display with 1280×720 resolution, a 1.5GHz NVidia Tegra3 quad-core processor, 12-core GPU and 13 million pixel camera, supporting 1080P HD video playback and recording. With an ultra-refined display and packing entertainment features including “Home Theater,” the ZTE Grand Memo LTE is well-equipped to take advantage of the fast data transmission speeds of 4G networks.



It’s said that the 4G Smartphone could be combines with 3G & WLAN, and it has the functions to transmit video and images in high quality. Regarding the price that users concern, the operator said the price is not higher than the WLAN contract. User could customize the service per the preference. The 4G download speed could reach up to 10 times of 3G link speed, which would let the 4G Smarpthone to watch vedio or transfer documents in large size smoothly; usually it takes only for few seconds.

Vodafone B2000 4G LTE Router

Vodafone B2000 is the direct successor to the B1000 LTE Router from Vodafone. This new 4G wireless gateway for housing is from the Chinese manufacturer Huawei. Someone may the B2000 looks similar to LTE CPE B593, but more specifically, it is just the Huawei B593 in Vodafone logo. Below we could see the key features and specifications of Vodafone B2000 4G LTE Router.









Features and characteristics of B2000 Vodafone LTE Router
Manufacturer and type designation B2000 (Huawei B593u-12)
Download Speed up to 100 Mbit/s
Upload Speed Up to 50 Mbit/s
Supported LTE bands: LTE Band 7/20 (800/2600MHz)
backward compatible with: HSPA, HSPA+, UMTS (900, 2100 MHz), GSM
MIMO Support: MIMO 2×2
Connector for external antenna Yes, 2 SMA female
Category: LTE Category 3 (3GPP Release 8) Router
Telephony
With integrated telephone system yes
Port for ISDN phones ?
Connection for analog phones yes, 2xRJ11
DECT ?
integrator answering machine –
Networking | LAN & WLAN
LAN ports 4 LAN ports (RJ45)
WLAN standards Wi-Fi 802.11b / g for up to 32 users
5 GHz Wi-Fi support no
Coding WEP, WPA, WPA2
USB Yes, USB 2.0
Information material
Manual Vodafone B2000 User Manual (PDF)
Available since … since April 2012 on Vodafone
Read Review B2000 Review
the provider side Vodafone





B2000 = Huawei B593



Following the Vodafone B1000, B2000 is with improved hardware based on support from the Chinese manufacturer Huawei. The appearance of B2000 looks like the ” Speedbox LTE “by Telekom, they are both from the original model Huawei B593u-12. With the demand from the operator, they adapted to the design for the respective mobile provider and logo. Thus, the B2000 from Vodafone comes in a white gown, while Telekom is focusing on noble black.







More power with LTE



First, the positive features with improved LTE attract eyes. While the B1000 “only” supported up to 50 Mbit/s, the B2000 now offers full support of up to 100 Mbps download speed and 50 Mbps upload transmission. The data is based on perfect network reception conditions. Huawei has also broadened the network support on Vodafone B2000. Instead of only on the LTE800 band, the B2000 can now also be used for LTE 2.6GHz (1.8 GHz would possibly be available after later firmware update). With backward compatible with 3G or 2G networks, when LTE is not available, it switches to HSPA, UMST, GSM or necessary. But for the B1000, this feature was not yet operational. Two external antennas can be connected via SMA connector to B2000 in case that the local reception conditions are not sufficient. A new feature is the telephone support, which is not supported by B1000.





Telephone and WLAN



Vodafone B2000 is the first time to bring telephones connection. If using B1000 Router, you had to combine with a DSL router to set up an LTE phone system or analog. B2000 LTE Router also supports VOIP, there are 2 RJ11 telephone interface. Local wireless networks can now be operated with the contemporary 802.11n WLAN standard with the B2000. That means up to 300 Mbps transfer rate could make true. Unfortunately, B2000 Router is lack of support the 5GHz band, but WEP encryption, WPA and WPA2 and 4 LAN Ports are available.



Now you can get the Vodafone B2000 4G LTE Router from www.4gltemall.com .

Unlocked ZTE MF821D 4G LTE Stick for O2

O2 offers the mobile use of LTE service since July 2012. The USB memory stick comes from the Chinese manufacturer ZTE, which also has various other versions for LTE in the range of products, such as LTE routers. The ZTE MF821D 4G stick is available for O2 4G LTE network and supports all cellular standards that are common in Germany. In the following table, you will find all the key figures, specifications of the O2 4G USB MF821D.





Features and Specifications of  ZTE MF821D for O2
Manufacturer and type designation ZTE MF821D
Download Speed 100 Mbit/s
Upload Speed 50 Mbit/s
Supported LTE bands LTE Band 3/7/20 (800/1800/2600MHz)
backward compatible with: DC-HSPA+, HSUPA, HSDPA, UMTS, EDGE, GPRS
MIMO Support: MIMO 2×2
Connector for external antenna yes, 2 antenna (TS-9 jacks)
LTE category: LTE Category 3 (3GPP Release 8) modem
Chipset Qualcomm MDM9200TM
Other
Dimensions 87.3 mm x 29.5 mm x 14 mm
USB standard USB 2.0
Memory card expansion Yes, MicroSD up to 32 GB
Compatible Operating Systems Windows XP, Windows Vista, Windows 7, Mac OS (10.4)
Manual or Quick Start Guide (PDF)  ZTE MF821D User Manual



With the ZTE MF821D, you receive a flexible surf stick that supports both LTE and all other major mobile communication standards, such as UMTS and HSPA+. O2 4G USB is therefore compatible with 2G, 3G and 4G networks. LTE can be received via the usual bands 3/7/20 (800/1800MHz/2600MHz). O2 uses LTE 800MHz for priority; the 4G network of LTE Band 7 (2600MHz) will be available in the cities in near future. The theoretical maximum download speed of 100Mbit/s and 50 Mbps upstream speed could be achieved. Currently, however, O2 offers “only” tariffs of up to 50 Mbps.









ZTE MF821D can work as the same as the data stick. The internal slot can hold MicroSD card up to 32 gigabytes. You can buy them from 4gltemall.com with the stick MF821D. The stick MF821D is perfect for mobile use on a laptop or notebook, and of course it can also be used at home on the desktop. It’s advisable that under certain circumstances, the data transmission rates vary depending on the local reception conditions. According to ZTE introduction, the MF821D stick is compatible with the Windows operating system with XP, ServicePack3, Vista SP2 or Windows 7, and Mac OS Version 10.5 is also supported.



At just 47 grams and the dimensions of 87.3 × 29.5 × 14 mm, you will hardly notice the MF821D in your pocket. The actual USB plug can be incidentally folded and thus saves space and it can also facilitates the connection as a “arm” for the laptop. Currently the stick is at O2 only in connection with an LTE tariff available. If you like this stick, you can buy unlocked ZTE MF821D from 4gltemall.com in good price.

And there is HUAWEI E392u-12 4G LTE Stick which could also work with the same 4G frequency bands for O2 and other 4G operators in Europe.
