Fibocom L610-IN LTE Cat 1 bis IoT Module

Fibocom L610-IN is an extremely cost-effective, high-performance LTE Cat 1 bis IoT module. The product supports LTE, GSM dual-mode communication, VoLTE, audio, camera, LCD, keypad and other functions. Some models support WIFI scanner Bluetooth.

In addition, the Fibocom L610-IN module provides universal interfaces such as USB / UART / SPI / I2C / SDIO to meet various application demands of the IoT industry. L610-IN covering the frequency bands of major operators in Asia, and L610-EU and L610-CN of the same series cover the frequency bands of major operators in Europe and Asia, respectively. L610 series products are packaged with LCC + LGA, and Pin design is compatible with NL668 series/ L716 series, which is convenient for customers to switch at minimum cost. The product covers the Internet of Things market with medium and low rates, such as pan payment, sharing, industrial interconnection, tracking, automotive aftermarket and other application scenarios. Provide perfect high-speed experience for customers in the above fields.

Fibocom L610-IN Module Specifications:

* Target region: India

* Package: LCC+LGA

* Dimension (mm): 31.0x28.0x2.35

* Frequency bands:
LTE FDD: B1/3/5/8
LTE TDD: B34/38/39/40/41
WCDMA: NA
GSM/GPRS/EDGE: 900/1800MHz

* Power Supply: <3.4V ~ 4.3V (Typical 3.8V)

* Operating Temp: -35°C ~ +75°C

* Extended Temp: -40°C ~ +85°C

* Data Transmission
LTE FDD (Mbps): 10.3(DL)/5.1(UL)
LTE TDD (Mbps): 9.1(DL)/3.1 (UL)
GPRS(Kbps): 85.6 (DL)/85.6 (UL)

* Functions
WiFi-Scan：NA
BLE： NA
OpenCPU：
FOTA： DFOTA
OS Drivers： Linux/Windows/Android
GNSS NA
TTS： Optional
SMS ●
Audio ●
Protocols： TCP/UDP(S)/HTTP(S)/FTP(S)/IPV4/IPV6/SSL/MQTT/NTP

* Interfaces
SIM x2, 1.8V/ 3.0V
USB x1,USB2.0
UART x3(Standard Edotion) x4(Open Edition)
I2C ●
SPI ●
ADC x3
GPIO ●
SDIO x2
I2S ●

* Regulation: RoHS
