Lierda LSD-FET430UIF2 MSP-FET Flash Emulation Tool
* Software configurable supply voltage between 1.8 V and 3.6 V at 100 mA
* Supports JTAG Security Fuse blown to protect code
* Supports JTAG and SWD lock on MSP432 devices to protect code
* Supports all MSP430 boards with JTAG header
* Supports JTAG and Spy-Bi-Wire (2-wire JTAG) debug protocols
* Supports ARM JTAG and ARM SWD debug protocols
Availability: In stock
Lierda LSD-FET430UIF2 Technical Specifications:
* Software configurable supply voltage between 1.8 V and 3.6 V at 100 mA
* Supports JTAG Security Fuse blown to protect code
* Supports JTAG and SWD lock on MSP432 devices to protect code
* Supports all MSP430 boards with JTAG header
* Supports JTAG and Spy-Bi-Wire (2-wire JTAG) debug protocols
* Supports ARM JTAG and ARM SWD debug protocols
Lierda LSD-FET430UIF2 Features
* USB debugging interface to connect any MSP430 MCU to a computer for real-time, in-system programming and debugging
* Enables EnergyTrace™ technology for energy measurement and debugging on all MSP430 and MSP432 devices in the Code Composer Studio and IAR Embedded Workbench development environments
* Supports tri-state mode to show “accurate” EnergyTrace power numbers
* Includes Backchannel UART for bi-directional communication between the MSP430 and a PC.
- This could enable simulation of inputs from sensors as well as logging of debug data while an application is running
- MSP BootStrapLoader (BSL) interface
* Up to 4x faster read/write speeds than the previous version of the FET programmer, MSP-FET430UIF
What's Included
* MSP-FET interface module
* 14-conductor cable
* Micro USB Cable
